1 x N one-side unit design
When designing the 1 x N one-side enclosure unit, add partitions between the products to keep the air paths separated.
– Refer to the “Vent opening design guide”. (Page 6)
– Make sure there is no gap between the partitions and the enclosure unit.
– Contact Samsung and guide when designing an N x M one-side enclosure unit.
Product 1
Product 2
Product 3
Partition
At least 50 mm
English - 8
OM46N / OM55N
