6
Anti-theft Lock
"
An anti-theft lock allows you to use the product securely even in public places.
"
The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.
"
The following images are for reference only. Real-life situations may differ from what is shown in the images.
"
Supported model: QB98R
To lock an anti-theft locking device:
1
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
2
Put one end of the cable through the loop on the other end.
3
Insert the locking device into the anti-theft lock slot at the back of the product.
4
Lock the locking device.
An anti-theft locking device can be purchased separately.
Refer to the user guide provided with your anti-theft locking device for details.
Anti-theft locking devices can be purchased at electronics retailers or online.

Other manuals for Samsung QB65R

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung QB65R and is the answer not in the manual?

Samsung QB65R Specifications

General IconGeneral
Product colorBlack
Product designDigital signage flat panel
Bezel width (side)9.2 mm
Placement supportedIndoor
Bezel width (bottom)11.2 mm
Panel mounting interface400 x 400 mm
Package depth185 mm
Package width1611 mm
Package height973 mm
Package weight33300 g
AC input voltage100 - 240 V
Heat dissipation618.9 BTU/h
AC input frequency50 - 60 Hz
Power consumption (sleep)0.5 W
Power consumption (standby)- W
Power consumption (typical)128 W
Color gamut92 %
Pixel pitch0.372 x 0.372 mm
Response time8 ms
Display diagonal64.5 \
Display brightness350 cd/m²
Display technologyLED
Vertical scan range48 - 75 Hz
Horizontal scan range30 - 81 kHz
LED backlighting typeEdge-LED BLU
Contrast ratio (typical)4000:1
Display number of colors16.78 million colors
Active display area (W x H)1428.48 x 803.52 mm
Dynamic contrast ratio marketing nameMega Contrast
User memory4.12 GB
Memory clock speed1500 MHz
VGA (D-Sub) input ports0
Ethernet LAN (RJ-45) ports1
Cables includedAC
PurposeUniversal
Operating hours (hours/days)16/7
Internal memory2.5 GB
Processor cores4
Processor modelA72
Processor familyARM Cortex
Processor frequency1.7 GHz
Audio formats supportedAC3
Image formats supportedJPEG, PNG
Video formats supportedAVC, AVS, H.263, H.264, HEVC, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9
Internal storage capacity8 GB
Operating system installedTizen 4.0
Certification60950-1, EMC B
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
RMS rated power20 W
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth46.3 mm
Width1453.9 mm
Height831 mm
Weight24900 g
