33
Connecting HDMI to Sound system and
Video device
"
Connecting parts may differ in different products.
After connecting a video device to the product using SOUND BAR HDMI Port an HDMI-DVI
cable, make sure to configure the settings as shown below.
MenuSystemGeneralHDMI Hot Plug to Off
HDMI 3 (ARC)
Connecting to an Audio System
"
Connecting parts may differ in different products.
"
Make sure to connect the same color connectors together. (white to white, red to red, etc.)
Connecting the LAN Cable
"
Connecting parts may differ in different products.
RJ45
 Use Cat7(*STP Type) cable for the connection. (10/100 Mbps)
*Shielded Twist Pair
