20
Before Installing the Product (Installation
Guide)
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the
installation instructions.
•
Ensure that an authorized installation company installs the wall mount.
•
Otherwise, it may fall and cause personal injury.
•
Make sure to install the specified wall mount.
Tilting Angle and Rotation
―
Contact Samsung Customer Service Center for further details.
Ventilation
―
Contact Samsung Customer Service Center for further details.
Installation on a Perpendicular Wall
A Minimum 40 mm
B Ambient temperature: Under 35 °C
―
When installing the product on a perpendicular wall, allow at least 40 mm
of space between the product and wall surface for ventilation and ensure
that the ambient A temperature is kept below 35 °C.
A
B
Installation on an Indented Wall
A Minimum 40 mm
B Minimum 70 mm
C Minimum 50 mm
D Minimum 50 mm
E Ambient temperature: Under 35 °C
―
When installing the product on an indented wall, allow at least the space
specified above between the product and wall for ventilation and ensure
that the ambient temperature is kept below 35 °C.
B
C
E
A
DD
