Locating the Units
(Continued)
When installing more than 1 outdoor unit
300 or more
300 or more
1500 or more 600 or more 3000 or more 300 or more3000 or more
600 or more 600 or more
300 or more1500 or more
600 or more 600 or more
600 or more
When 3 sides of the outdoor unit are blocked by the wall
When the walls are blocking front and the rear side of the outdoor units
When front and rear side of the outdoor unit is toward the wall
When the air outlet is toward the wall
(Unit : mm)
1500 or more
600 or more 600 or more
