Samsung RF267ABBP/XAA User Manual

setting up _11
4. Remove four 10mm hex-head bolts from both sides.
5. Lift the freezer door up from the rails.
2. Remove the tilting pocket(
1
) by pulling on both brackets(
2
)
upward at the same time.
3. Take out the lower basket(
3
) by lifting the basket up from
rail system.
1. Push the upper drawer until it reaches to the cabinet rear wall.
DISASSEMBLE THE FREEZER DRAWER
1
2
3
Slot
Slot
01 SETTING UP
DA68-01819A.indb 11 2009.9.22 3:9:36 PM

Samsung RF267ABBP/XAA Specifications

General

Brand	Samsung
Model	RF267ABBP/XAA
Category	Refrigerator
Language	English
