12_ Setting Up
Setting up your French Door Refrigerator
REATTACHING THE REFRIGERATOR DOORS
Assemble the Refrigerator doors
1. Reattach the lower left and right door hinges(
12
).
With a Philips head screwdriver, insert and tighten the
two screws(
10
) into the lower left and right door hinges.
With a Allen Wrench(3/16”), insert and tighten the two hex
head bolts(
11
) into the lower left and right door hinges.
2. Place the hole in the bottom of the door over the lower
hinge(
12
).
Be careful not to miss the hinge cap because it can
be easily taken off.
3. Insert the upper hinges(
9
) into the holes at the top
of the doors.
With a Wrench(10mm), insert and tighten the 3 hex
head bolts(
7
) into the upper left and right door
hinges.
With a Philips head screwdriver, insert and tighten
the ground screw(
8
) into the upper left and right
door hinges.
9
7
8
12
10
11
12
