3. Pull out ice box subassembly framework.
5.Hold down the terminal hook and draw out the
terminal in the direction of the arrow.
4.Remove the four screws from the air-duct front
cover that shall be drawn out in the direction of
the arrow.
36
6.Remove the two screws from the air-duct
subassembly back cover.
remove the
two screws
