1.Remove the screw from the lampshade and
unclench two latches at one-side with a
1-shaped screwdriver to take off the lampshade.
Alert
When changing the refrigerating compartment lamp, disconnect the power to avoid an
electric shock.
2.Turn off the lamp.
3.When the new lamp is fitted, setup the lampshade
latches from right to left as well as the screws.
2
1
2
1
35
1. Take out the freeze compartment drawer.
2.Remove the two screws from the air-duct
subassembly framework.
Two screws
9. DISASSEMBLE & ASSEMBLY
9-1 Change The Refrigerating Compartment Lamp
9-2 Disassembly of the Freeze Compartment Air-duct Subassembly
To Next Page
