7.Take apart the air-duct subassembly in the
direction of arrow and take down the plug-ins,
such as sensors etc.
Assembly of The Freeze Air-duct Subassembly
Keep 9 (refrigerant
and noise down)
Evaporator framework
Evaporator
Main evaporator
sensor
Temperature fuse
