26
Lift the guard up and pull it out from door liner
1. Pull the shelf out as far as it goes.
2. Lift it up and pull it out from the unit.
The water filter is
located in the upper
left hand corner of the
refrigerator. this filter
filters water for ice
maker & water
dispenser.
1. Turn the water
filter 1/2 turn
counterclockwise
and pull it down.
2. To install the filter
align the indication
mark(unlock
position) and push it up while turning
1/2 turn clockwise up to the lock position is
aligned. Do not over tighten.
1. Remove all shelves.
2. Remove two screws that secured.
3. Disconnect the wire connector.
4. Remove the screw for disassembling the
PBA board for controlling CoolSelect zone
TM
Door Guard in REFRIGERATOR
CoolSelect zone
TM
(Optional)
Shelves
Water filter
To Next Page
