96
13. Machine Room Assembly Specification
13-1) Please remove fixed screw of cover of machine room of Refrigerator rear low part.
13-2) Machine Room Assembly Specification
Electric Field Box
Condensing Unit
Compressor
Dryer
Cooling Fan
