Samsung RS21 - Page 87

87
Illustrated Parts Catalog.
NNOO CCOODDEE--NNOO PPAARRTT NNAAMMEE
21
22
23
24
24-1
24-2
24-3
24-4
24-5
24-6
24-7
24-8
24-9
24-10
24-11
25
25-1
25-2
25-3
26
26-1
26-2
27
DA63-00162B
4713-001132
DA63-00364A
DA97-00360P
DA63-00153B
DA62-00186A
DA72-00227A
DA61-00417A
DA63-00713A
DA31-00038A
DA31-00020E
DA39-00060B
DA63-01146A
6002-000471
DA61-20128A
DA96-00090B
DA32-00006B
DA47-10148J
DA61-00603A
DA97-00339B
DA47-00092B
DA70-00404A
DA63-00157A
COVER SENSOR-B
LAMP-INCANDESCENT
COVER LAMP-FRE,A
ASSY COVER EVAP-FRE LOW)
COVER EVAP-FRE(FRONT LOW)
INSULATION DUCT-FRE
SEAL-AIR FRE LOW
CASE MOTOR
COVER-MOTOR
FAN-CIRCUIT
MOTOR DC-BLDC,SENSOR
WIRE HARNESS-MOTOR
GROMMET-MOTOR
SCREW-TAPPING
SPRING ETC-FAN
ASSY EVAP-FRE
SENSOR ASSY
THERMO FUSE-ASSY
FIXER-SENSOR
ASSY-PLATE DRAIN,FRE
HEATER DRAIN-FRE
PLATE-DRAIN FRE
COVER-LAMP
■■
Part List of Freezer Room
SSppeecc QQuuaannttiittyy RReemmaarrkk
ABS , PNC-2
240V , 30W
PP
PP
FOAM-PS
OJC-3000 , T5
ABS SCRAP
PP
ABS
DREP3020LA,ET,0.245
F-FAN
NBR , ID6.5 , OD42
TH,+,1,M4,L12,PASS,STS304
STS27 , PI7.8 , ID1.0
230V
PX-41C RD SEN,A TOP,-10°C~
SW-102T , 250V
PP
230V , 41W
230V , 41W
GALVALUME , T0.5
GPPS
2
3
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
