Illustrated Parts Catalog.
NNOO CCOODDEE--NNOO PPAARRTT NNAAMMEE
1
2
3
4
5
6
6-1
6-2
7
8
9
10
11
11-1
11-2
12
12-1
12-2
13
14
15
16
17
18
19
-
DA63-30232K
DA61-00776A
DA66-90112C
6002-000468
DA97-00904A
DA63-00199B
DA73-00216A
DA63-00635A
DA71-00090A
DA63-00590A
6002-000470
DA64-00111B
DA64-00095B
DA71-00078A
DA64-00209A
DA64-00098B
DA64-00196A
DA64-00097B
DA64-00100E
DA64-00099B
DA71-00077A
6002-000213
6002-000468
DA64-00096B
ASSY DOOR FOAM REF
GASKET DOOR-REF ASSY
STOPPER DOOR
CAM HINGE-RISER,LOW
SCREW-TAPPING
ASSY COVER-GUARD
COVER-GUARD
RUBBER-COVER GUARD
GUARD BOTTLE-REF,UPP
GUIDE-BOTTLE REF
GUARD REF-LOW
SCREW-TAPPING
HANDLE-LOW-ASSY
HANDLE BASE-LOW
REINF-HANDLE LOW
HANDLE TRIM-ASSY,MID
HANDLE TRIM-MID
TRIM-HANDLE CONNECT,MID
HANDLE BASE-UPP
HANDLE-TRIM UPP
HANDLE TRIM-LOW
REINF-HANDLE-MID
SCREW-TAPPING
SCREW-TAPPING
HANDLE BASE-MID
■■
Part List of Refrigerator Room Door Exploded View
SSppeecc QQuuaannttiittyy RReemmaarrkk
-
SF-PVC
SHP1 , T3.0
NY-66
PH,+,2S,M5.0,L18,ZPC(YEL)
GPPS
SILICONE
HIPP
PP
HIPP
TH,+,1,M4,L10
SNOW-WHITE
HIPP , SNOW-WHITE
SBHG1 , T1.4
ABS , SNOW-WHITE
ABS , SNOW-WHITE
SILVER COLOR
HIPP , SNOW-WHITE
ABS , SNOW-WHITE
ABS , SNOW-WHITE
SBHG1 , T1.4
TH,+,1,M4,L12,ZPC(YEL)
PH,+,2S,M5.0,L18,ZPC(YEL)
HIPP , SNOW-WHITE
1
1
1
1
4
1
1
2
2
1
2
3
1
1
1
1
1
2
1
1
1
1
3
4
1
