Used for Inverter Model
100
PCB DIAGRAM
6-10) Inverter PCB
(Inverter comp control Board)
COMP ķ U
ĸ V
Ĺ W
COMP OLP
OLP
POWER(220V)
ķ 12V
ĸ 5V
Ĺ GND
ĺ COMP RPM
