TROUBLE SHOOTING
5) The 7-Segment Load Status is as follows.
Freezer Fridge
50
NO
ITEM Description Display Digital no.
Damper
OVER-LOAD MODE
Over 34 Ambient Temp
LOW-TEMP MODE
Less than 21 Ambient Temp
EXHIBIT MODE
Exhibition Mode On
COMPRESSOR COMP On
FREEZER FAN HIGH F-FAN HIGH RPM
FREEZER FAN LOW F-FAN LOW RPM
FREEZER DEFROST HEATER
F-DEF HEATER ON
CONDENSER FAN HIGH C-FAN HIGH RPM
CONDENSER FAN LOW C-FAN LOW RPM
DISPENSER HEATER
Dispenser Heater On
NORMAL CONDITIONS
& All Off(22~33
)
Fridge first digit g
Fridge second digit e
Fridge second digit f
Fridge second digit g
Freezer second digit a
Freezer second digit b
Freezer second digit c
Freezer second digit d
Freezer second digit e
Freezer second digit f
Freezer second digit g
Fridge second digit e,f LED all Off
Load Mode Check List
Fridge
(first)
Fridge
(second)
Fridge
(second)
Fridge
(second)
Freezer
(second)
Freezer
(second)
Freezer
(second)
Freezer
(second)
Freezer
(second)
Freezer
(second)
Freezer
(second)
Fridge
(second)
ĸĹ
Damper Open
1) If the panel display is reset upon instant power failure, it will trigger nonsense calls at the call center.
To prevent this, the following measure is implemented into the unit. Upon the power supply, it initializes
the unit or brings back its previous settings based on the Freezer temperature.
2) Upon the initial power on, it checks its Freezer temperature. When it is lower than +5
, it is to be
considered as an instant power failure and it brings back all its previous operation functions (Power
Freeze, Power Cool, Vacation, Freezer Settings, Fridge Settings, Ice Type, Child Lock, etc) related to
the panel display.
3) When it is higher than +5
, it is to be considered as a long-period power failure and it will initialize the
panel display (Freezer: -20
, Fridge: 3 , Cubed).
4-1-4) Restoration of Previous Settings Upon Power Failure
To Next Page
