Samsung RSA1D series Service Manual

68
56$=56$-56$'56$8
NO CODE NO PART NAME Specification
Q
uantit
y
Remark Electric Part
1
DA97-06012A ASSY SHELF FRE-HIGH 2
1-1
DA67-01907A SHELF FRE-HIGH HIPS 1
1-2
DA64-02458A GLASS-SHELF FRE HIGH GLASS,T3.2 1
2
DA97-06013A ASSY SHELF FRE-LOW 2
2-1
DA67-01904A SHELF FRE-LOW HIPS 1
2-2
DA64-02459A GLASS-SHELF FRE LOW GLASS,T3.2 1
2
DA97-06013A ASSY SHELF FRE-LOW 1
2-1
DA67-01904A SHELF FRE-LOW HIPS 1
2-2
DA64-02459A GLASS-SHELF FRE LOW GLASS,T3.2 1
3
DA97-06065A ASSY-CASE BASKET HIGH 1
3-1
DA61-04009A CASE-BASKET HIGH PP 1
3-2
DA63-04045A COVER-BASKET FRONT HIGH HIPS 1
3-3
DA63-04044A COVER-BASKET FRONT HIGH SAN 1
3
DA97-06065A ASSY-CASE BASKET HIGH 2
3-1
DA61-04009A CASE-BASKET HIGH PP 1
3-2
DA63-04045A COVER-BASKET FRONT HIGH HIPS 1
3-3
DA63-04044A COVER-BASKET FRONT HIGH SAN 1
4 DA97-01291B ASSY RAIL-BASKET L 1
4-1 DA61-00044C RAIL-BASKET L HIPS(TALC-PP) 1
4-2 DA63-00202A GROMMET-RAIL NY-6 1
4 DA97-01291B ASSY RAIL-BASKET L 2
4-1 DA61-00044C RAIL-BASKET L HIPS(TALC-PP) 1
4-2 DA63-00202A GROMMET-RAIL NY-6 1
5 DA97-01292B ASSY RAIL-BASKET R 1
5-1 DA61-00045C RAIL-BASKET R HIPS(TALC-PP) 1
5-2 DA63-00202A GROMMET-RAIL NY-6 1
5 DA97-01292B ASSY RAIL-BASKET R 2
5-1 DA61-00045C RAIL-BASKET R HIPS(TALC-PP) 1
5-2 DA63-00202A GROMMET-RAIL NY-6 1
6
DA63-04055A COVER-BASKET HIGH HIPS 1
7
DA97-06066A ASSY-CASE BASKET LOW 1
7-1
DA61-04046A CASE-BASKET LOW PP 1
7-2
DA63-04042A COVER-BASKET FRONT LOW
B
HIPS 1
7-3
DA63-04040A COVER-BASKET FRONT LOW
A
SAN 1
8
DA97-06072A ASSY TRAY-ICE BUCKET 1
8-1
6002-000215 SCREW-TAPPING TH
,
1
,
M4.0
,
L16
,
ZP
C
8
8-2
DA62-01659A SEAL-POM A SR-S7183
,
POM
,
W2
8-3
DA62-01660A SEAL-POM B SR-S7184
,
POM
,
W2
8-4
DA31-00207A BLADE-MOVING A STS304,T2.0 1
8-5
DA31-00206A BLADE-MOVING B STS304,T2.0 1
8-6
DA31-00205A BLADE-MOVING C STS304,T2.0 1
8-7
DA31-00209A BLADE-STATIONARY DISP OU
T
STS304,T 1
8-8
DA31-00208A BLADE-STATIONARY DISP IN STS304,T2 1
8-9
DA61-03865A FIXER-GUARD SR-S7180,POM, 1
8-10
DA61-03864A GUIDE-ICE DISPENSER HIPS,W45.2 1
8-12
DA66-00529A LEVER-CUBE MSWR10 1
8-13
DA61-03947A SPRING ETC-DISPENSER SR-S7180
,
STS30
4
1
8-14
DA61-03972A FIXER-AUGER HEX
,
POM
,
AURGE 1
8-15
DA60-00185A FASTENER-RING SK-5H,SR-S7180 1
8-16
DA60-00186A FASTENER-WASHER ID20
,
OD28
,
T0.5
,
S
T
1
8-17
DA63-03934A TRAY ICE-BUCKET PP,WHITE 1
8-18
DA63-04019A COVER-ICE BUCKET PP,WHI 1
8-19
DA63-03935A COVER-CRUSHER DISP HIPS, 1
8-20
DA65-00049A CLAMPER HOSE-HELIX QUEEN,PC 1
RSA1D
RSA1U
56$=
56$-
RSA1Z
RSA1J
56$=
56$-
RSA1D
RSA1U
RSA1D
RSA1U
RSA1D
RSA1U
RSA1Z
RSA1J
RSA1D
RSA1U
