Samsung RSA1D series Service Manual

87
Parts List of Fridge Door
(RSA1J RSA1D RSA1U RSA1N RSA1S)
NO CODE NO PART NAME Specification Quantity Remark Electric Part
1
DA91-02675A ASSY DOOR FOAM REF 1
2
DA90-04251B ASSY GASKET-DOOR REF 1
3
DA97-06256A ASSY HANDLE-BAR 1
3-1
DA64-02389A HANDLE BAR ABS,LONG BAR 1
3-2
DA67-01886A CAP-HANDLE ABS,T2,NTR,LONG 4
3-3
6002-000216 SCREW-TAPPING TH
,
+
,
-
,
1
,
M4
,
L12
,
ZPC
(
W
H
4
3-4
6002-001341 SCREW-SPECIAL BH
,
+
,
-
,
M4
,
L16
,
ZPC
(
WHT 4
3-5
DA61-03906A SUPPORT-HANDLE NY66,NTR 4
3-6
DA61-03951A STOPPER-HANDLE SK5 4
3
DA64-02389A ASSY HANDLE-BAR 1
3-1
DA64-02412A HANDLE BAR ABS,HALF BAR 1
3-2
DA67-01886A CAP-HANDLE ABS,T2,NTR,LONG 2
3-3
DA67-01887A CAP-SUPT HANDLE ABS,SC-00477R 2
3-4
DA61-03906A SUPPORT-HANDLE NY66,NTR 2
3-5
6002-001341 SCREW-SPECIAL BH,+,-,M4,L16,ZPC
(
WHT 2
3-6
DA61-03951A STOPPER-HANDLE SK5 2
4
DA97-05891A ASSY GUARD-DAIRY 1
4-1
DA63-03955A GUARD-DAIRY ABS,T2.5,COOL 1
4-2
DA63-03954A COVER-GUARD DAIRY GPPS/HF2660 1
5
DA63-03999A GUARD REF-UPP PP,COOL W 1
6
DA97-05890A ASSY GUARD REF-MID 1
6-1
DA63-03998A GUARD REF-MID PP
,
-
,
-
,
-
,
COOL WHITE
,
1P 1
6-2
DA61-03993A GUIDE BOTTLE-REF PP
,
T2.5
,
-
,
-
,
COOL-WHIT
E
1
7
DA63-03997A GUARD REF-LOW PP,COOL W 1
8
ASSY-BRACKET HANDLE 2
8-1
DA61-03927A BRACKET-HANDLE SWRC10A,FH 1
8-2
DA63-03943A GROMMET-HANDLE SILICON,T1 1
8
ASSY-BRACKET HANDLE 4
8-1
DA61-03927A BRACKET-HANDLE SWRC10A,FH 1
8-2
DA63-03943A GROMMET-HANDLE SILICON,T1 1
T Handle
H Handl
e
H Handle
T Handle
