Samsung RVXVHT100FE - Cycle Function Parts

36
8
Cycle function parts
8-1. RVXVHT075/100FE
Accumulator
Suction temperature sensor
EVI EEV
PWM(Pulse Width Modulation) valve
Hot gas
bypass valve
Suction
temperature
sensor
Outdoor
Main EEV
Refrigerant
charging port in
heating mode
4 way valve
Liquid tube
sensor
EVI bypass
valve
EVI EEV
Sump(Base) temp. sensor Oil balancing valve bracket
Liquid
service valve
Cond_out
temp.
sensor
Hot gas
bypass
valve
High
pressure
sensor
DVI(Digital Vapor Injection) compressor 1
Low pressure sensor
Oil separator
High pressure switch
Liquid bypass valve
for FVI compressor
Liquid bypass valve
for FVI compressor
Discharge
temperature sensor
Low pressure sensor
Liquid bypass valve
for DVI compressor
Discharge
temperature sensor
Liquid bypass valve
for DVI compressor
FVI(Fixed Vapor Injection)
compressor 1
Oil balancing valve
High pressure sensor
Fan
Gas service
valve
