Specifications
Type
Model Name RVXVHT075FE RVXVHT100FE RVXVHT125FE
Power Supply Ø/ V/ Hz
3/ 208~230/ 60 3/ 208~230/ 60 3/ 208~230/ 60
Mode
1)
-
Heat Pump Heat Pump Heat Pump
Performance
US Ton TON
6.0 8.0 10.0
Horse Power HP
7.5 10.0 12.5
Nominal
Capacity
Cooling
2)
Btu/h
72,000 96,000 120,000
US RT
6.0 8.0 10.0
Heating
3)
Btu/h
81,000 108,000 135,000
US RT
6.8 9.0 11.3
Power
Nominal Input
Cooling
kW
5.50 7.50 10.70
Heating
5.15 7.08 10.09
Nominal Running
Current
Cooling
A
18.80 28.90 36.80
Heating
22.60 24.90 33.00
Circuit Breaker (MCCB/ELB/ELCB) A
50 50 60
COP
Cooling -
3.84 3.75 3.29
Cooling (US Only) Btu/Wh
13.09 12.80 11.21
Heating -
4.61 4.47 3.92
Compressor
Model
ZPJ72KCE-TF5
ZPI61KCE-TF5
ZPJ72KCE-TF5
ZPI61KCE-TF5
ZPJ83KCE-TF7
ZPI83KCE-TF7
Type -
DVI Scroll FVI Scroll DVI Scroll FVI Scroll DVI Scroll FVI Scroll
Number EA
1 1 1 1 1 1
Piston Displacement
cc/Rev
67.1 58.1 67.1 58.1 77.2 77.2
in³/Rev
4.095 3.545 4.095 3.545 4.711 4.711
Output kW
6.94 5.83 6.94 5.83 7.91 7.91
Lubricant
Type -
3MAF POE 3MAF POE 3MAF POE
Charging
cc
1,685 1,685 1,685 1,685 1,685 1,685
fl. oz.
57 57 57 57 57 57
Fan
Type / Control -
Propeller/BLDC Propeller/BLDC Propeller/BLDC
Motor Output W
630 630 630
Airflow Rate
m
3
/min
170 170 180
CFM
6004 6004 6357
External Static
Pressure
Max.
Pa
78.5 78.5 78.5
WG
0.315 0.315 0.315
Safety
Devices
Mechanical Type
-
High Pressure Switch High Pressure Switch High Pressure Switch
-
Comp./Accum. Crank Case Heater Comp./Accum. Crank Case Heater Comp./Accum. Crank Case Heater
-
Fuse for PCB Fuse for PCB Fuse for PCB
Electronic Type
-
Over-voltage Protection Over-voltage Protection Over-voltage Protection
-
Current Transformer Current Transformer Current Transformer
-
Fan motor Voltage Protection Fan motor Voltage Protection Fan motor Voltage Protection
Piping
Connections
Liquid
Ø, mm
9.52 9.52 12.70
Ø, inch
3/8 3/8 1/2
Gas
Ø, mm
19.05 22.23 28.58
Ø, inch
3/4 7/8 1 1/8
Oil (Flare)
Ø, mm
- - -
Ø, inch
- - -
Installation
Limitation
Max. Length
m
200 200 200
ft
656 656 656
Max. Height
m
50 (40) 50 (40) 50 (40)
ft
164 (131) 164 (131) 164 (131)
Refrigerant
Type -
R410A R410A R410A
Factory Charging
kg
6.5 7.5 9.0
lbs
14.33 16.53 19.84
Sound
4)
Sound Pressure dB(A)
58 58 60
Set Size
Net Weight
kg
240 240 280
lbs
529 529 617
Shipping Weight
kg
253 253 297
lbs
558 558 655
Net Dimensions (WxHxD)
mm
880 x 1668 x 765 880 x 1668 x 765 1200 x 1668 x 765
inch
34 5/8 x 65 5/8 x 30 1/8 34 5/8 x 65 5/8 x 30 1/8 47 1/4 x 65 5/8 x 30 1/8
Shipping Dimensions (WxHxD)
mm
948 x 1888 x 832 948 x 1888 x 832 1268 x 1888 x 832
inch
37 3/8 x 74 3/8 x 32 3/4 37 3/8 x 74 3/8 x 32 3/4 49 7/8 x 74 3/8 x 32 3/4
Cable
Main Power (Below 50m) AWG #
AWG 6 AWG 6 AWG 4
Communication AWG #
AWG 16~18 AWG 16~18 AWG 16~18
Operating
Temp. Range
Cooling
°C
-5~46.1 -5~46.1 -5~46.1
°F
23~115 23~115 23~115
Heating
°C
-20~24 -20~24 -20~24
°F
-4~75 -4~75 -4~75
*1) Mode
HP : Heat Pump, HR : Heat Recovery
*2) Norminal cooling capacities are based on;
Indoor temperature : 26.7°C DB, 19.4°C WB(80°F DB, 67°F WB)
Outdoor temperature : 35°C DB, 23.9°C WB(90°F DB, 75°F WB), Equivalent refrigerant piping : 7.6m(25ft) , Level differences : 0m(0ft)
*3) Norminal heating capacities are based on;
Indoor temperature : 21.1°C DB, 15.6°C WB(70°F DB, 60°F WB)
Outdoor temperature : 8.3°C DB, 6.1°C WB(47°F DB, 43°F WB), Equivalent refrigerant piping : 7.6m(25ft) , Level differences : 0m(0ft)
*4) Sound level was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications are subject to change without prior notice for product improvement.
