Samsung RVXVHT100FE - Electric Specifications

45
Installation
4
Electric specifications
4-1. Basic models
4-2. Combinations
Classification Capacity (Ton) Capacity (HP) Model MCCB(A) ELB
Single unit
6 7.5 RVXVHT075FE 50 50A, 30mA 0.1 Second or less
8 10.0 RVXVHT100FE 50 50A, 30mA 0.1 Second or less
10 12.5 RVXVHT125FE 60 60A, 30mA 0.1 Second or less
Model
Units Power supply Comp. OFM
Hz Volts Min. Max. MCA MFA RLA kW FLA
RVXVHT075FE 60 208~230 187 253 48.1 50 13.8 + 21.8 0.63 7
RVXVHT100FE 60 208~230 187 253 53.8 50 19.6 + 21.8 0.63 7
RVXVHT125FE 60 208~230 187 253 61.1 60 23.4 + 24.6 0.63 7
Classification
Capacity
(Ton)
Capacity
(HP)
Basic model
MCCB(A) ELB
RVXVHT075FE RVXVHT100FE RVXVHT125FE
Module unit
12 15.0 2 50 + 50
14 17.5 1 1 50 + 50
16 20.0 2 50 + 50
18 22.5 1 1 50 + 60
20 25.0 2 60 + 60
22 27.5 1 2 50 + 50 + 50
24 30.0 3 50 + 50 + 50
26 32.5 2 1 50 + 50 + 60
28 35.0 1 2 50 + 60 + 60
30 37.5 3 60 + 60 + 60
Model
Units Power supply Comp. OFM
Hz Volts Min. Max. MCA MFA RLA kW FLA
RVXVHT150FE 60 208~230 187 253 96.2 50+50 (13.8+21.8)×2 0.63+0.63 7+7
RVXVHT175FE 60 208~230 187 253 101.9 50+50 (13.8+21.8)+(19.6+21.8) 0.63+0.63 7+7
RVXVHT200FE 60 208~230 187 253 107.6 50+50 (19.6+21.8)×2 0.63+0.63 7+7
RVXVHT225FE 60 208~230 187 253 114.9 50+60 (19.6+21.8)+(23.4+24.6) 0.63+0.63 7+7
RVXVHT250FE 60 208~230 187 253 122.2 60+60 (23.4+24.6)×2 0.63+0.63 7+7
RVXVHT275FE 60 208~230 187 253 155.7 50+50+50 (13.8+21.8)+(19.6+21.8)×2 0.63+0.63+0.63 7+7+7
RVXVHT300FE 60 208~230 187 253 161.4 50+50+50 (19.6+21.8)×3 0.63+0.63+0.63 7+7+7
RVXVHT325FE 60 208~230 187 253 168.7 50+50+60 (19.6+21.8)×2+(23.4+24.6) 0.63+0.63+0.63 7+7+7
RVXVHT350FE 60 208~230 187 253 176.0 50+60+60 (19.6+21.8)+(23.4+24.6)×2 0.63+0.63+0.63 7+7+7
RVXVHT375FE 60 208~230 187 253 183.3 60+60+60 (23.4+24.6)×3 0.63+0.63+0.63 7+7+7

All wiring, components and materials to be procured on the site must comply with the applicable local and national codes.

The relationship between the starting time and the starting current (Digital Scroll Comp. + Fixed Scroll Comp)

RLA is based on the following conditions.
- Indoor temp. : 80˚F DB/ 67˚F WB
- Outdoor temp. : 95˚F DB

Voltage range
Units are suitable for use on electrical systems where voltage
supplied to unit terminal is not below or above listed range limits.

Maximum allowable voltage variation between phases is 2%.

Select wire size based on the value of MCA.

MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).

Abbreviations
- MCA: Min. Circuit Amps. (A)
MCA = 1.25 X LOAD1 + LOAD2
(LOAD1: RLA of Digital Comp. / LOAD2: RLA of Fixed Comp. + FLA of Fan Motor)
- MFA: Max. Fuse Amps. (A)
- RLA: Rated Load Amps. (A)
- OFM: Outdoor Fan Motor
- FLA: Full Load Amps. (A)
- kW : Rated Motor Output (kW)
Starting current
Starting time
RLA
