Samsung SCD20 - Page 12

Samsung Electronics 1-11
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
601 AD63-00403A COVER-LEFT 2.5”;DELTA-PJ,ABS 94HB,-,-,-, 2.5”
601 AD63-00403B COVER-LEFT 2.5”;DELTA-PJ,ABS 94HB,-,-,-, 2.5”
601 AD63-00410A COVER-LEFT 3.5”;DELTA-PJ,ABS 94HB,-,-,-, 3.5”
601 AD63-00410B COVER-LEFT 3.5”;DELTA-PJ,ABS 94HB,-,-,-, 3.5”
602 AD97-02047A ASSY-SPEAKER;-,VP-D65,ASSY-SPEAKER
604 AD97-06444A ASSY-LEFT BOARD;DELTA-PJ,SC-D23,ASSY LEF
605 AD97-06479A ASSY-UNIT CASE LEFT;,DELTA, SCD21
605 AD97-06479D ASSY-UNIT CASE LEFT;,DELTA, SCD23/24
605 AD97-06479G ASSY-UNIT CASE LEFT;,DELTA, SCD27/29
605 AD97-06479K ASSY-UNIT CASE LEFT;,DELTA, SCD20
607 AD63-00395A COVER-DUMMY 2.5”;DELTA-PJ,ABS 94HB,-,-,- SCD23/24
607 AD63-00395C COVER-DUMMY 2.5”;DELTA-PJ,ABS 94HB,-,-,- SCD21
607 AD63-00395E COVER-DUMMY 2.5”;DELTA-PJ,ABS 94HB,-,-,- SCD20
607 AD63-00411A COVER-DUMMY 3.5”;DELTA-PJ,ABS 94HB,-,-,- SCD27/29
607 AD63-00411C COVER-DUMMY 3.5”;DELTA-PJ,ABS 94HB,-,-,-
607 AD63-00411D COVER-DUMMY 3.5”;DELTA-PJ,ABS 94HB,-,-,-
613 AD64-00943A KNOB-SELECT;DELTA-PJ,ABS 94HB,-,-,-,-,BL
614 AD61-01138A HOLDER-SELECT;DELTA-PJ,ABS 94HB,-,-,-,-, 2.5”
614 AD61-01240A 3.5”
615 AD63-00394A COVER-DOOR M/S;DELTA-PJ,ABS 94HB,-,-,-,-
616 AD61-01100A HOLDER-DOOR M/S;DELTA-PJ,ABS 94HB,-,-,-, 2.5”
616 AD61-01241A 3.5”
617 AD61-01028A SPRING ETC-DOOR M/S;BETA-PJ,SUS304 WPB,-
618 AD61-01170A BRACKET-TRIPOD;DELTA-PJ,PC,-,-,-,-,-
620 AD61-01118A BRACKET-SHOULDER;DELTA-PJ,SUS304,T1,-,-,
621 AD63-00393A COVER-DC JACK;DELTA-PJ,TPE,-,-,-,-,-,-,?
622 AD69-00045B PAD-LCD;DELTA-PJ,PORON,T1.5,-,-,-,L-GR
630 3809-001435 FFC CABLE-FLAT;-,-,100MM,10P,0.5MM,-
631 3809-001438 FFC CABLE-FLAT;-,-,100MM,45P,0.5MM,-
903 AC60-12128A SCREW-TAP TITE BH;-,-,-,FE,BH,4 1.7,l4,-
908 6003-001291 SCREW-TAPTITE;CH,+,B,M1.4,L3.0,ZPC(BLK),
