Samsung Electronics 1-13
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
850 AD97-06485A ASSY-TOP;.,DELTA-PJ,EXP
851 AD97-06477A ASSY-MIC;.,DELTA-PJ,ASSY MIC
853 AD97-06439A ASSY-TOP BOARD;.,SC-D23,ASSY TOP BOARD
855 AD61-01032A SPRING ETC-ZOOM;BETA-PJ,SUS,-,-,-,-,-,-,
856 AD61-01140A HOLDER-ZOOM;DELTA-PJ,POM,NAT,-,-,-,-,-
858 AD61-12033A BRACKET-NUT;SV-D10,T0.8,-,-,-,-,T0.8
860 AD61-01143A CASE-TOP;DELTA-PJ,ABS 94HB,-,-,-,-,-
861 AD64-00944A KNOB-ZOOM;DELTA-PJ,ABS,NAT,-,-,-,-,BLK,-
862 AD64-00945A GRILLE-MIC LEFT;DELTA-PJ,WIRE MASHI,T0.3
863 AD63-00422A SHEET-MIC
903 AC60-12128A SCREW-TAP TITE BH;-,-,-,FE,BH,4 1.7,l4,-
To Next Page
