Samsung Electronics 2-11
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RP12 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP13 2007-000139 R-CHIP;220ohm,5%,1/16W,DA,TP,1005
RP15 2007-000140 R-CHIP;1Kohm,5%,1/16W,DA,TP,1005
RP16 2007-000171 R-CHIP;0ohm,5%,1/16W,DA,TP,1005
RP17 2007-000164 R-CHIP;150Kohm,5%,1/16W,DA,TP,1005
RP18 2007-007001 R-CHIP;3.9KOHM,5%,1/16W,DA,TP,1005
RP19 2007-007001 R-CHIP;3.9KOHM,5%,1/16W,DA,TP,1005
RP20 2007-000775 R-CHIP;33Kohm,5%,1/16W,DA,TP,1005
RP21 2007-000153 R-CHIP;22Kohm,5%,1/16W,DA,TP,1005
RP23 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP25 2007-000140 R-CHIP;1Kohm,5%,1/16W,DA,TP,1005
RP28 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP29 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP30 2007-001307 R-CHIP;180ohm,5%,1/16W,DA,TP,1005
RP31 2007-001307 R-CHIP;180ohm,5%,1/16W,DA,TP,1005
RP32 2007-000159 R-CHIP;56Kohm,5%,1/16W,DA,TP,1005
RP33 2007-000159 R-CHIP;56Kohm,5%,1/16W,DA,TP,1005
RP34 2007-000775 R-CHIP;33Kohm,5%,1/16W,DA,TP,1005
RP36 2007-000164 R-CHIP;150Kohm,5%,1/16W,DA,TP,1005
RP37 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP38 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP40 2007-000172 R-CHIP;10ohm,5%,1/16W,DA,TP,1005
RP41 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
RP42 2007-000148 R-CHIP;10Kohm,5%,1/16W,DA,TP,1005
X201 2801-003703 CRYSTAL-SMD;24.576MHz,50ppm,28-ACI,12pF,
X202 2801-003424 CRYSTAL-SMD;41.85MHZ,50ppm,28-ACC,12pF,-
X701 2801-004237 CRYSTAL-SMD;12.5MHZ,50PPM,28-ABV,13PF,60
X702 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12.5
XA01 2804-001309 OSCILLATOR-CLOCK;54MHZ,20PPM,10TTL & CMO
ASSY-CCD BOARD
CC01 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC04 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
CC05 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC06 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CNC01 3710-001106 CONNECTOR-SOCKET;40P,2R,0.8mm,SMD-S,SN
CNC02 3708-001687 CONNECTOR-FPC/FFC/PIC;27,0.3MM,SMD-A,SN
DC01 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
QC01 0505-000180 FET-SILICON;2SK1070,N,-,50mA,-,150mW,SOT
RC01 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608
RC02 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
RC03 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
ADAPTOR-AC POWER;100/240V,50HZ/60HZ,-,-,
C10 2203-000455 C-CERAMIC,CHIP;1NF,5%,50V,C0G,TP,2012
C11 2301-001092 C-FILM,MPEF;100nF,20%,275V,BK,18x6x12,15
C12 2401-003302 C-AL;47uF,20%,400V,GP,TP,18X31.5,7.
C13 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5
C14 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C15 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C16 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C30 2201-000828 C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,TP,15X
C50 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20,5
C51 2401-000037 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
C55 2203-000239 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,2012
C57 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C58 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C59 2203-000938 C-CERAMIC,CHIP;0.47NF,5%,50V,C0G,TP,2012
C61 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C62 2401-000438 C-AL;10uF,20%,25V,GP,-,5x11,2mm
C63 2203-000455 C-CERAMIC,CHIP;1NF,5%,50V,C0G,TP,2012
CON1 3721-001034 PLUG-AC POWER;2P,-,-,NI
CON2 3711-000900 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH
D10 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D11 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D12 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D13 0402-000137 DIODE-RECTIFIER;1N4007,1000V,1A,DO-41,TP
D14 0402-001041 DIODE-RECTIFIER;ERA22-10,1000V,500mA,MSR
D15 0402-001041 DIODE-RECTIFIER;ERA22-10,1000V,500mA,MSR
D50 0402-001062 DIODE-RECTIFIER;SF10SC9,90V,10A,FTO-220,
D52 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT-
D53 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
D54 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
D55 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
F10 3601-000207 FUSE-CARTRIDGE;250V,1A,TIME-LAG,GLASS,5.
IC10 1203-002180 IC-PWM CONTROLLER;5M0265,TO220F-4L,4P,39
IC50 AC14-12006D IC;KA431Z,TO-92,TAPING
IC51 AC14-12001K IC;KA324,-,-
J10 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J11 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J50 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J51 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J52 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J53 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J55 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J56 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J57 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
J61 AC38-12001U WIRE-JUMPER(H-WRAP);1007#26,120M/M
To Next Page
