Samsung Electronics2-12
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
L50 AC27-12001N COIL CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
LF10 AC27-32001F COIL-LINE FILTER;BSF-2123,20MH,2OHM,ST,-
PC10 0604-000119 PHOTO-COUPLER;TR,200-400%,200mW,DIL-4,ST
Q52 0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,350MW,SOT-
R00 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R10 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R11 2007-000481 R-CHIP;1MOHM,5%,1/8W,DA,TP,3216
R13 2003-000771 R-METAL OXIDE(S);68Kohm,5%,2W,AA,TP,4x12
R14 2007-000598 R-CHIP;22OHM,5%,1/8W,DA,TP,3216
R15 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R16 2007-000768 R-CHIP;330OHM,5%,1/8W,DA,TP,3216
R17 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R18 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R19 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R20 2007-001212 R-CHIP;82KOHM,5%,1/8W,DA,TP,3216
R21 2001-000374 R-CARBON;15OHM,5%,1/4W,AA,TP,2.4X6.4MM
R30 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
R30 2201-001005 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,11X
R30A 2201-001005 C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,TP,11X
R50 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R51 2007-000472 R-CHIP;1KOHM,5%,1/8W,DA,TP,3216
R53 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R54 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R55 2007-000312 R-CHIP;10OHM,5%,1/8W,DA,TP,3216
R57 2007-000938 R-CHIP;47KOHM,1%,1/10W,DA,TP,2012
R58 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R59 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R60 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R61 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
R62 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R63 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R64 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R65 2007-000868 R-CHIP;4.7KOHM,1%,1/10W,DA,TP,2012
R66 2007-000406 R-CHIP;15KOHM,1%,1/10W,DA,TP,2012
R68 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R70 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012
R71 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R72 2007-000582 R-CHIP;22KOHM,1%,1/10W,DA,TP,2012
R74 2007-001205 R-CHIP;82KOHM,1%,1/10W,DA,TP,2012
R76 2005-000102 R-WIRE WOUND;0.1ohm,1%,1W,AA,TP,4.5x11mm
R77 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
R79 2007-001067 R-CHIP;6.8KOHM,1%,1/10W,DA,TP,2012
R80 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
T10 AD26-00026A TRANS POWER;AA-E6,AA-E6,1.4mH,6P,100~260
VR50 2101-001049 VR-ROTARY;500ohm,-,-,-
ASSY-REAR BOARD
CNR01 3710-001106 CONNECTOR-SOCKET;40P,2R,0.8mm,SMD-S,SN
CNR02 3710-001478 CONNECTOR-SOCKET;18P,2R,1MM,SMD-S,SN
CNR03 3711-000862 CONNECTOR-HEADER;BOX,3P,1R,1.25mm,SMD-A,
CR10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CR20 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
FER01 0505-001726 FET-SILICON;ECH8603,P,-20V,-4A,37MOHM,1.
ICR01 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
LDR01 0601-001006 LED;CHIP,Y-GRN,1.3x2.9mm,570nm
QR01 0504-001102 TR-DIGITAL;EMD3,NPN/PNP,150MW,10K/10K,EM
QR02 0504-000168 TR-DIGITAL;RN1104,NPN,100MW,47K/47K,SSM,
QR03 0504-000168 TR-DIGITAL;RN1104,NPN,100MW,47K/47K,SSM,
QR04 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
RR01 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR02 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RR03 2007-008596 R-CHIP;0.1OHM,1%,1/2W,TP,3216
RR04 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
RR05 2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608
RR06 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
RR07 2007-000651 R-CHIP;27Kohm,1%,1/16W,DA,TP,1608
RR08 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR09 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608
RR10 2007-000923 R-CHIP;470Kohm,1%,1/16W,DA,TP,1608
RR11 2007-000563 R-CHIP;220Kohm,1%,1/16W,DA,TP,1608
RR20 2007-000043 R-CHIP;1Kohm,1%,1/16W,DA,TP,1608
RR21 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RR30 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
RR31 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
RR32 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RR33 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RR34 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RR35 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RR36 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
SWR01 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SWR03 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SWR05 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SWR06 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SWR08 3404-001130 SWITCH-TACT;12VDC,50mA,160gf,6.1x3.7x2.5
VRR01 3406-001005 SWITCH-ROTARY;5V,0.1mA,DPST,-
BTR01 AD65-00019A TERMINAL-PLATE BATTERY B;-,C5210R-H, T0.
BTR02 AD65-00019A TERMINAL-PLATE BATTERY B;-,C5210R-H, T0.
JR01 AD97-04964A ASSY-DC JACK;3P,ALPHA-PJ,DDAE-0174
LBTR01 AD63-00074A TERMINAL—LI BATT(+);M1-PJ,C5210R-H,T0.2
LBTR02 AD63-00075A TERMINAL—LI BATT(-);M1-PJ,C5210R-H,T0.2
SWR07 3403-001084 SWITCH-PUSH;DC5V,1 MA,-,ON-OFF,-
