Samsung SCD20 - Page 38

Samsung Electronics 2-13
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
ASSY-LEFT BOARD
CLF01 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CLF02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CLF05 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNLF01 3708-001813 CONNECTOR-FPC/FFC/PIC;45P,0.5MM,SMD-A,SN
CNLF02 3708-001236 CONNECTOR-FPC/FFC/PIC;10P,0.5mm,SMD-A,SN
CNLF03 3708-001112 CONNECTOR-FPC/FFC/PIC;26P,0.5mm,SMD-A,SN
CNLF04 3708-001022 CONNECTOR-FPC/FFC/PIC;18P,0.5mm,ANGLE,SN
CNLF05 3711-000541 CONNECTOR-HEADER;BOX,2P,1R,1.25MM,SMD-A,
CNLF06 3711-000922 CONNECTOR-HEADER;BOX,4P,1R,1.25mm,SMD-A,
RLF01 2007-000651 R-CHIP;27Kohm,1%,1/16W,DA,TP,1608
RLF02 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RLF03 2007-001206 R-CHIP;82Kohm,1%,1/16W,DA,TP,1608
RLF04 2007-000633 R-CHIP;270Kohm,1%,1/16W,DA,TP,1608
RLF05 2007-000651 R-CHIP;27Kohm,1%,1/16W,DA,TP,1608
RLF06 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RLF10 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RLF11 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF12 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF14 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF15 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF16 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF20 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF21 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF22 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF23 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF24 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF25 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF26 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF27 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF28 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF29 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF30 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF31 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF32 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF33 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF34 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF35 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF36 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF37 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF38 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF39 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RLF40 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RLF41 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RLF42 2007-000606 R-CHIP;240ohm,1%,1/16W,DA,TP,1608
RLF43 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RLF44 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
SOC01 3709-001214 CONNECTOR-CARD EDGE;10P,1.5MM,SMD-A,AUF
SWLF013404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF023404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF033404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF043404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF053404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF063404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF073404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF083404-000119 SWITCH-TACT;12V,50mA,100gf,5.2x5.2x0.8mm
SWLF103409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
ASSY-LCD BOARD
CL101 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL102 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL104 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL107 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL110 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL111 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL137 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL138 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL148 2301-001108 C-FILM,CHIP;22nF,5%,50V,TP,3.2x2.5x1.4,3
CL150 2203-005040 C-CERAMIC,CHIP;0.012nF,5%,3kV,NP0,TP,452
CL157 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL158 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL160 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL161 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL208 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL209 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL210 2404-000232 C-TA,CHIP;4.7uF,20%,10V,-,TP,3216,-
CL211 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL231 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL232 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL302 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL303 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL316 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL317 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL318 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL319 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL331 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
CL332 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CL344 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL401 2404-001269 C-TA,CHIP;10UF,20%,20V,-,TP,3528
CL412 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
