Samsung Electronics2-14
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CL415 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
CL416 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
CL417 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
CL418 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
CL419 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL421 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
CL422 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNL301 3708-001829 CONNECTOR-FPC/FFC/PIC;28P,0.5mm,SMD-A,TI
CNL302 3708-001749 CONNECTOR-FPC/FFC/PIC;26P,0.5MM,SMD-A,SN
DL303 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
ICL01 1003-001474 IC-LCD DRIVER;AN2545NFHQ,LQFP,48P,49MIL,
ICL202 1103-001133 IC-EEPROM;24C020,256x8BIT,SOP,8P,150MIL,
ICL301 1201-001086 IC-OP AMP;75S558,SOP,5P,62.9MIL,DUAL,100
LED01 0601-001097 LED;CHIP,GRN,1.6x1.4mm,560nm
LL102 2703-000407 INDUCTOR-SMD;330uH,10%,3.2x2.5x2.2mm
LL104 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL105 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL109 2703-002271 INDUCTOR-SMD;100UH,-,5.5X5.5X2MM
LL115 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
LL201 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL304 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL307 2703-000407 INDUCTOR-SMD;330uH,10%,3.2x2.5x2.2mm
LL401 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
QL103 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
QL108 0502-001221 TR-POWER;CPH3209,NPN,900MW,CPH3,TP,200-
QL109 0502-001221 TR-POWER;CPH3209,NPN,900MW,CPH3,TP,200-
QL110 0501-002311 TR-SMALL SIGNAL;HN2A01FU,PNP,200mW,UMD6,
QL306 0501-000552 TR-SMALL SIGNAL;2SA1774-Q,PNP,150mW,EM3,
RL136 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL137 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL140 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RL141 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
RL142 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL201 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RL202 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RL203 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RL204 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RL205 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RL301 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
RL302 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL303 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RL304 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL305 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RL306 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL307 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL308 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL309 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL310 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
RL311 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL312 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL313 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL314 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL315 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RL316 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RL317 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RL319 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RL320 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RL321 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL322 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL323 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL428 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL430 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RL431 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RL432 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
TL103 2601-001090 TRANS-SMD,PULSE;100MH,760,-,10.1X10.1X2.
ASSY-EVF BOARD
CE01 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE04 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CE05 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
CE07 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE12 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE13 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
CE14 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CE15 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CE16 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE17 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE20 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CNE01 3708-001680 CONNECTOR-FPC/FFC/PIC;6P,0.5MM,SMD-A,SN
CNE02 3708-001076 CONNECTOR-FPC/FFC/PIC;20P,0.5MM,SMD-S,SN
DE02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
DE03 0404-000110 DIODE-SCHOTTKY;RB411D,20V,500mA,SOT-23,T
DE04 0403-001421 DIODE-ZENER;KDZ2.7V,2.5-2.9V,150MW,SOD-3
ICE01 1003-001373 IC-LCD DRIVER;MCVVQ111FB,LQFP,48P,276MIL
