Samsung Electronics 2-15
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
LE01 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LE03 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LED01 0601-001586 LED;CHIP,WHT,-,470NM
QE02 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U
RE01 2007-001125 R-CHIP;68Kohm,1%,1/16W,DA,TP,1608
RE02 2007-001068 R-CHIP;6.8Kohm,1%,1/16W,DA,TP,1608
RE05 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608
RE06 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RE07 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RE16 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RE17 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RE20 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RE21 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RE22 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RE25 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RE26 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RE29 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RE30 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RE31 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VRE02 2104-001007 VR-SMD;10Kohm,25%,0.15W,TOP
ASSY-TOP BOARD
CNT01 3711-000922 CONNECTOR-HEADER;BOX,4P,1R,1.25mm,SMD-A,
RT01 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
RT02 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
SWT01 2102-001019 VR-SLIDE;10Kohm,30%,1/20W,SLIDE
SWT02 3404-001130 SWITCH-TACT;12VDC,50mA,160gf,6.1x3.7x2.5
