Alignment and adjustment
5-8 Samsung Electronics
SC-L100 SC-L150
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
AB 11 11 11 11 FOCUS RESET POSITION H
AC 4B 4B 4B 4B ZOOM RESET POSITION L
AD 12 12 12 12 ZOOM RESET POSITION H
AE 83 83 83 83 ZOOM RESET DIFERRENCE
AF 40 40 40 40 AF FILTER1 DATA MAGNIFY RATO
B0 C0 C0 C0 C0 FILTER1 NOISE LEVEL(L) OF AREA1
B1 OO OO OO OO FILTER1 NOISE LEVEL(H) OF AREA1
B2 C0 C0 C0 C0 FILTER1 NOISE LEVEL(L) OF AREA2
B3 02 02 02 02 FILTER1 NOISE LEVEL(H) OF AREA2
B4 90 90 90 90 FILTER2 NOISE LEVEL(L) OF AREA1
B5 OO OO OO OO FILTER2 NOISE LEVEL(H) OF AREA1
B6 E0 E0 E0 E0 FILTER2 NOISE LEVEL(L) OF AREA2
B7 01 01 01 01 FILTER2 NOISE LEVEL(H) OF AREA2
B8 20 20 20 20 NOISE SLICE START AGC
B9 FE FE FE FE NOISE SLICE MAXIMUM VALUE
BA 30 30 30 30 CHROMA SUPRESS START AGC
BB O3 O3 O3 O3 CHROMA SUPRESS MAXIMUM VALUE
BC 30 30 30 30 EY BLACK START AGC
BD O4 O4 O4 O4 EY BLACK MAXIMUM VALUE
BE A0 A0 A0 A0 AE TAGET OF NEGA MODE(FADE IN)
BF 77 77 77 77 H/V ADJUST OF D ZOOM HEADER COMMEND
C0 2A 2A 2A 2A FADE LIMIT OF NEGA MODE
C1 28 28 28 28 DATA CONTROL BOUNDARY OF OUTDOOR
C2 24 24 24 24 NEGA MODE W/B R-CONTROL DATA
C3 A1 A1 A1 A1 FOCUS RETURN LOW BYTE
C4 15 15 15 15 FOCUS RETURN HIGH BYTE
C5 A0 A0 A0 A0 ZOOM RETURN LOW BYTE
C6 12 12 12 12 ZOOM RETURN HIGH BYTE
C7 O5 O5 O5 O5 LENS CHECK MARGIN (WIDE)
C8 12 12 12 12 LENS CHECK MARGIN (TELE)
C9 65 65 65 65 ADJUST MODE IRIS SETTING DATA
CA 7F 7F BF BF D ZOOM RAITO
CB O6 O6 O6 O6 AE UP/DOWN OF NEGA MODE BLC
CC 00 00 00 00 SETUP ADJUST ENABLE
CD 70 70 70 70 HALL AUTO ADJUSTMENT
CE D0 D0 D0 D0 IRIS CONTROL RANGE ADJUSTMENT
CF FF FF FF FF WHITE BALANCE AUTO ADJUSTMENT
D0 FF FF FF FF LENS AUTO ADJUSTMENT
D1 FF FF FF FF HALL AUTO CHECK
D2 FF FF FF FF AGC AUTO CHECK
D3 FF FF FF FF LENS CHECK OF PCB LINE
D4 FF FF FF FF GYRO SENSOR CHECK (H)
D5 FF FF FF FF GYRO SENSOR CHECK (V)
D6 80 80 80 80 ZOOM VR CENTER AUTO ADJUSTMENT
D7 01 01 01 01 ZOOM/FOCUS CHECK ENABLE
D8 20 20 20 20 VR ZOOM CENTER MARGEIN
D9 00 00 00 00 COLOR GAIN ADJUSTMENT
DA 7E 7E 7E 7E SETUP AUTO ADJUSTMENT
DB O8 O8 O8 O8 HALL CHECK THRESHOULD
DC 82 82 82 82 COLOR ADJUST TARGET VALUE
DD 89 89 89 89 HALL ADJUST GAIN TARGET
DE 4D 4D 4D 4D HALL ADJUST CENTER
DF 00 00 00 00 NOT USED
E0 AA AA AA AA BK NOISE TH/GAIN OF EIS
E1 5F 5F 5F 5F H APPERTURE GAIN OF EIS
E2 FF FF FF FF #0C OF EIS ON
E3 07 07 07 07 #OD OF EIS ON
E4 A8 A8 A8 A8 #OE OF EIS ON
E5 10 10 10 10 #OF OF EIS ON
E6 OO OO OO OO #18 OF EIS ON
