152 AD90-10824W ASSY-MAIN BOARD;VP-L10/BASIC,PAL,NOR,MON VPL100
152 AD90-10831L ASSY-MAIN BOARD;SC-L100/BASIC,NTSC,NOR,M SCL100
152 AD90-10838T ASSY-MAIN BOARD;SC-L150/BASIC,NTSC,NOR,M SCL150
152 AD90-10838U ASSY-MAIN BOARD;VP-L150/BASIC,PAL,NOR,MO VPL150
AUDIO BLOCK
C701 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C702 2203-002220 C-CERAMIC,CHIP;56PF,5%,50V,CH,TP,1608,-
C703 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C704 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C705 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C706 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C707 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C708 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C709 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C710 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C711 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C712 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C713 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C714 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C715 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m
C716 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C717 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C718 2402-001009 C-AL,SMD;100UF,20%,6.3V,GP,TP,5.3X5.3X5
C719 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C720 2404-000107 C-TA,CHIP;100nF,20%,35V,-,TP,3216,-
C721 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C722 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C723 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C724 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C725 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C726 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C728 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C729 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C750 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
C751 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C752 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C753 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C851 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C852 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
C853 2404-000107 C-TA,CHIP;100nF,20%,35V,-,TP,3216,-
C854 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
C855 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C856 2203-001662 C-CERAMIC,CHIP;5.6nF,10%,50V,CH,TP,1608,
CN702 3708-001141 CONNECTOR-FPC/FC/PIC;18P,0.8mm,SMD-A,SN
CN851 3711-002612 CONNECTOR-HEADER;3WALL,5P,1R,1.25MM,SMD-
IC701 AC11-12001C IC-ROM;LA7454W,QFP,-
IC750 1201-001207 IC-AUDIO AMP;7052A,DIP,8P,-,SINGLE,35.5M
L701 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L750 2703-000407 INDUCTOR-SMD;330uH,10%,3.2x2.5x2.2mm
Q750 0501-000171 TR-SMALL SIGNAL;2SB1119,PNP,500MW,PCP,TP
Q751 0504-000110 TR-DIGITAL;DTC114EU,NPN,200mW,10K-10Kohm
Q851 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q852 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
R701 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R702 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R704 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R705 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R706 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
R707 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R708 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R709 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R710 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R711 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R712 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R713 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R714 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R715 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R716 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R719 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R720 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R721 2007-000691 R-CHIP;3.3Mohm,5%,1/16W,DA,TP,1608
R722 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
R723 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R724 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R726 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R728 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R730 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R731 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R750 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R751 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R752 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R753 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R754 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R755 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R850 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R851 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R852 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R853 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R854 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R855 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R856 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
R857 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R858 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R859 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R860 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP 200
R861 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R862 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R863 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
R864 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R865 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R866 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
CAMERA MAIN BLOCK
CNP01 3710-001110 CONNECTOR-SOCKET;18P,2R,0.8mm,SMD-S,AUF
CNP02 3708-001262 CONNECTOR-FPC/FC/PIC;22P,0.5mm,SMD-A,SN
CNP03 3711-002049 CONNECTOR-HEADER;BOX,6P,1R,1.25mm,SMD-A,
CP01 2203-001083 C-CERAMIC,CHIP;5pF,0.1pF,50V,NPO,TP,1608
CP02 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP05 2203-001083 C-CERAMIC,CHIP;5pF,0.1pF,50V,NPO,TP,1608
CP06 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP08 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP09 2203-001699 C-CERAMIC,CHIP;8pF,0.5pF,50V,CH,1608,1.6
CP10 2203-001699 C-CERAMIC,CHIP;8pF,0.5pF,50V,CH,1608,1.6
CP11 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP12 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP13 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP14 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP20 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP21 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP22 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP23 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP24 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP25 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP26 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CP27 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CP28 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
CP29 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
CP30 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
CP31 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP32 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP34 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CP35 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP37 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP38 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP39 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
