Alignment and adjustment
5-12 Samsung Electronics
SC-L100 SC-L150
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
6C OO OO OO OO HORIZENTAL START READ ADDRESS -H
6D O1 O1 O1 O1 HORIZENTAL START READ ADDRESS -L
6E OO OO OO OO HORIZONTAL D ZOOM START SUB PIXEL
6F OO OO OO OO V D ZOOM START SUB PIXEL ODD FIELD
70 OO OO OO OO V D ZOOM START SUB PIXEL EVEN FIELD
71 36 36 36 36 OUTDOOR R-Y POSITIVE GAIN
72 2C 2C 2C 2C OUTDOOR R-Y NEGATIVE GAIN
73 O5 O5 O5 O5 OUTDOOR R-Y POSITIVE HUE
74 13 13 13 13 OUTDOOR R-Y NEGATIVE HUE
75 23 23 23 23 OUTDOOR B-Y POSITIVE GAIN
76 1B 1B 1B 1B OUTDOOR B-Y NEGATIVE GAIN
77 18 18 18 18 OUTDOOR B-Y POSITIVE HUE
78 04 04 04 04 OUTDOOR B-Y NEGATIVE HUE
79 48 48 48 48 R VALUE OF SEPIA MODE
7A 20 20 20 20 G VALUE OF SEPIA MODE
7B 78 78 78 78 R VALUE OF YELLOW MODE
7C 60 60 60 60 G VALUE OF YELLOW MODE
7D 88 88 88 88 HALL REFERENSE START VALUE
7E 3A 3A 3A 3A HALL GAIN START VALUE
7F 4B 4B 4B 4B HALL MINIMUM VALUE (IRIS OPEN)
80 D7 D7 D7 D7 HALL MAXIMUM VALUE(IRIS CLOSE)
81 18 18 18 18 OUTDOOR DETECT IRIS CTL VALUE
82 30 30 30 30 AE TARGET (LOW BYTE)
83 O5 O5 O5 O5 AE TARGET (HIGH BYTE)
84 A0 A0 A0 A0 IRIS CONTROL MIN VALUE
85 3A 3A 3A 3A IRIS CONTROL MAX VALUE
86 02 02 02 02 TARGET MARGEIN OF IRIS ADJUSTMENT
87 12 12 12 12 CCD WHITE DEFFECTS ADJUSTMENT
88 85 85 85 85 AGC MAXIMUM CONTROL
89 10 10 10 10 NOT USED
8A 09 09 09 09 BLC ON AE TARGET
8B 48 48 48 48 CINEMA/SPOT LIGHT BLC TARGET
8C O8 O8 O8 O8 SAND/SNOW MODE AE TARGET
8D O8 O8 O8 O8 NEGA MODE AE TARGET
8E OA OA OA OA NOT USED
8F 88 88 88 88 WHITE BALANCE R TARGET
90 70 70 70 70 WHITE BALANCE B TARGET
91 45 45 45 45 R INDOOR START VALUE OF W/B ADJUSTMENT
92 85 85 85 85 B INDOOR START VALUE OF W/B ADJUSTMENT
93 65 65 65 65 R OUTDOOR START VALUE OF W/B ADJUSTMENT
94 68 68 68 68 R INDOOR START VALUE OF W/B ADJUSTMENT
95 3C 3C 3C 3C R INDOOR CONTROL VALUE
96 98 98 98 98 B INDOOR CONTROL VALUE
97 75 75 75 75 R OUTDOOR CONTROL VALUE
98 5C 5C 5C 5C B OUTDOOR CONTROL VALUE
99 O2 O2 O2 O2 R OUTDOOR CONTROL UP/DOWN MARGIN
9A 83 83 83 83 R INDOOR CONTROL UP/DOWN MARGIN
9B O3 O3 O3 O3 B INDOOR CONTROL UP/DOWN MARGIN
9C 8D 8D 8D 8D B OUTDOOR CONTROL UP/DOWN MARGIN
9D 88 88 88 88 INITIAL(POWER ON) R CTL START DATA
9E OO OO OO OO INITIAL(POWER ON) B CTL START VALUE
9F 6E 6E 6E 6E W/B TABLE MODE
A0 O2 O2 O2 O2 W/B SD/3+AEAVR-MAXDETE
A1 90 90 90 90 W/B CONTROL BOUNDARY
A2 A6 A6 A6 A6 W/B CTL STOP HALL OF MACRO AREA
A3 48 48 48 48 W/B OUTDOOR STOP HALL
A4 8A 8A 8A 8A R OUTDOOR CONTROL UP/DOWN OF W/B ADJUST
A5 48 48 48 48 CINEMA AE TAGET
A6 30 30 30 30 CINEMA / SPOT AE TAGET
A7 20 20 20 20 W/B STABLE CONDITION
