Alignment and adjustment
5-44 Samsung Electronics
11. Custom Code setting.
: This setting is displayed to A.CUSTOM in OSD.
You donÕt need to set this adjustment mode.
-.Press the MENU(mode change) button to move to the next adjustment
mode.
*. If you want to stop adjustment, do power resourcing.
12. Model Number setting.
: This setting is performed for definition of the specification
according to the model name
1) Get into the VCR adjustment.
2) Confirm the adjustment mode is 9:HD SWP. in OSD.
If not, fit the adjustment mode with the MENU(mode change) button.
3) The number according to model is showed below.
-.SCL100 : 10 -.SCL150 : 15
-.VP-L100 : 10 -.VP-L150 : 15
4) Press the DISPLAY(data-up) or the C.RESET(data-down) until the EVR:XX is to be what you want.
5) Be sure to press the TITLE(confirm) button to update the setting..
6) If completed, press the MENU(mode change) button to move to the next adjustment mode.
*. If you want to stop adjustment, do power resourcing.
