Exploded View and Parts List
Samsung Electronics 6-3
Loc. No New Part No Description and Specification Remark
101 AD64-30905E CASE-LEFT;-,ABS94,V0,BLACK,-,VP-L100,-,- VPL100
101 AD64-30905F CASE-LEFT;-,ABS94,V0,BLACK,-,SCL100,-,- SCL100
101 AD64-30905H CASE-LEFT;-,ABS94,V0,BLACK,-,SCL150,-,- VPL150/SCL150
102 AD64-82001B LEG-3INCH;-,ABS,-,T1.5,BLK,-,VP-L100
104 AD64-10812A KNOB-POWER;-,ABS,-,-,-,SV-S99
105 AD64-10880A KNOB-EJECT;-,ABS,HB,BLK,-,VP-L100
106 AC61-42079A STOPPER-POWER;ABS94HB,T1.0,-,RED,SV-H66,
107 AD61-60601A SPRING-KNOB POWER;SUS304 WPB
108 AD61-21020A HOLDER-POWER;-,-,-,BLK,-,SV-S99
109 AD64-10814E KNOB-ROTARY;-,ABS94,HB,D/GRAY,-,VP-L100
110 AD90-10828F ASSY-FUNC VCR BOARD;VP-L10 S8C-PAL,3INCH
111 AD61-21021A HOLDER-ROTARY;-,-,-,BLK,-,SV-S99
112 AD90-10828D ASSY-FUNC TION BOARD;VP-L10 S8C-PAL,3INCH
113 AD39-20825N LEAD CONNECTOR-ASSY;-,51021-05,51021-02,
114 AC61-20223A HOLDER-LOCK;SECC,T1.0,NAT,-,-,-
115 AC61-60034A SPRING-EJECT;CS,SUS 304,PI 0.25,D 3,L 9,
116 AD61-21040A HOLDER-EJECT;-,POM,-,BLK,-,SV-S99
117 AD98-12016G ASSY-UNIT LCD OFF;SV-S99,-
118 AC62-12009A INSULATION-SPEAKER;HIMERON,-,T0.3,W30,L3
119 AD73-10039A RUBBER-SPEAKER;SILICONE,-,SCL90,-
120 AD59-90400A SPEAKER-SYSTEM;28G13BSA,SCL90,SEA
121 AD61-10999A BRACKET-SPEAKER;-,SECC,SV-S99
122 AD90-10828E ASSY-FUNC MEN BOARD;VP-L10 S8C-PAL,3INCH
123 AD39-20826D LEAD CONNECTOR-ASSY;TP,51021,51021,12P,8
124 AD61-12024A BRACKET-HINGE;-,SUS,SCL90
125 AD61-12013A BRACKET-GUIDE HINGE;-,SUS,SV-S99
126 AD98-12025A ASSY-LENS HOOD;VP-L100,-
127 AD98-12025B ASSY-CASE FRONT;VP-L100,- VPL100
127 AD98-12025H ASSY-CASE FRONT;SCL100,- VPL150/SCL100
127 AD98-12025J ASSY-CASE FRONT;SCL150,- SCL150
129 AD98-12024P ASSY-MIC;VP-A20,-
130 AD90-10833K ASSY-FRONT BOARD;VP-L100,NOR,MONO VPL100/SCL100
130 AD90-10837Y ASSY-FRONT BOARD;VP-L150,NOR,MONO VPL150/SCL150
131 AD59-10539A UNIT-CASE FRONT;VP-L100,- VPL100
131 AD59-10539B UNIT-CASE FRONT;SCL100,- SCL100
131 AD59-10539C UNIT-CASE FRONT;SCL150,- SCL150
131 AD59-10539D UNIT-CASE FRONT;VP-L150,- VPL150
132 AD64-30903C CASE-HINGE TOP;-,ABS,HB,BLACK,-,VP-L100,
133 AD41-20302Y FPC-LCD;POLYWIDE,T0.10,18P,VP-L100
134 AD98-12003N ASSY-HINGE;SV-S99,-
135 AD64-30881E CASE-HINGE BOTTOM;-,ABS94,HB,-,-,BLACK,-
136 AD63-30537A COVER-BRKT HINGE;-,ABS94HB,-,BLACK,-,SV-
137 AD64-10816A KNOB-LCD MIRROR;-,ABS,-,-,-,SV-S99
138 AD61-60578A SPRING-MIRROR;-,-,SUS304,-,D0.25,-,SV-S9
139 AD61-12035A BRACKET-SUPP HINGE;-,SUS T1.0,SV-S99
140 AD64-30901G CASE-LCD TOP;-,ABS94,VO,-,-,L/GRAY,-,VP- VPL100
140 AD64-30901K CASE-LCD TOP;-,ABS94,VO,-,-,L/GRAY,-,VP- VPL150
140 AD64-30901L CASE-LCD TOP;-,ABS94,VO,-,-,L/GRAY,-,SCL SCL150
140 AD64-30901M CASE-LCD TOP;-,ABS94,V0,-,-,D/GRAY,-,SV- SCL100
141 AD90-10828B ASSY-LCD BOARD;VP-L100,PAL 3 VPL150/VPL100
141 AD90-10831J ASSY-LCD BOARD;SC-L100/BASIC,NTSC 3 SCL150/SCL100
142 AD61-12022A BRACKET-LCD;-,SUS,SCL90
143 AD90-30205Z ASSY-BL;SV-S90,3
144 AD07-10032J LCD-PANNEL;DP,COD30T3008T,SV-S99,3
145 AD61-50687A GUIDE-LCD OPEN;-,ABS,-,T1.5,BLK,-,SV-S99
146 AD61-60569A SPRING-LCD LOCK;-,-,SUS304,-,D0.3,-,SV-S
147 AD61-30183A LOCKER-LCD OPEN;-,POM,-,BLK,-,SV-S99
148 AD64-10815A KNOB-LCD OPEN;-,ABS,-,-,-,SV-S99
149 AD64-30902C CASE-LCD BOTTOM;-,ABS94,V0,-,-,L/GRAY,-,
902 AC60-10019A SCREW-MACHINE;BH,+,M2,X4,FZB,FE,UP,-,-
903 AC60-10020A SCREW-MACHINE;BH,+,M2,X5,FZB,FE,UP,-,-
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB
906 AC60-10073A SCREW-TAPTITE;BH,+,-,M2,X6,ZP4,FE
