Exploded View and Parts List
Samsung Electronics 6-5
Loc. No New Part No Description and Specification Remark
100 AD96-10473H ASSY-8MM DECK;DE-6BNN,- SCL100/150
100 AD96-10473L ASSY-8MM DECK;DE-6BPN,- VPL100/150
152 AD90-10824W ASSY-MAIN BOARD;VP-L10/BASIC,PAL,NOR,MON VPL100
152 AD90-10831L ASSY-MAIN BOARD;SC-L100/BASIC,NTSC,NOR,M SCL100
152 AD90-10838T ASSY-MAIN BOARD;SC-L150/BASIC,NTSC,NOR,M SCL150
152 AD90-10838U ASSY-MAIN BOARD;VP-L150/BASIC,PAL,NOR,MO VPL150
153 AD90-10808D ASSY-FPC PRE-AMP;VP-A57/SEG,VCR-MAIN
154 AD90-10828G ASSY-CCD BOARD;VP-L10,S8C-PAL-CCD VPL150/VPL100
154 AD90-10831H ASSY-CCD BOARD;SC-L100/BASIC,NTSC 3 SCL150/SCL100
155 AC63-62007A SPACER-CCD;SILICON,-,BLK,-,VP-K70,-
156 AC29-92002D FILTER-OLP;SV-3C01MM,KSS,-,-
157 AD90-10827Z ASSY-LENS ZOOM;VP-A20,SEC 16X ZOOM
158 AD59-10443A UNIT-FRAME LENS;SV-S99/DOM,-
159 AD61-12015A BRACKET-DECK BOTTOM;-,SUS,SV-S99
160 AD61-12014A BRACKET-DECK TOP;-,SUS,SV-S99
161 AD41-20303A FPC-DECK;POLYWIDE,T0.1,48P,VP-A20
162 AD98-11254B ASSY-CASE TOP;VP-L100,-
167 AD64-30898C CASE-BOTTOM;-,ABS,-,BLACK,-,CS97V-AN,-,-
168 AD61-22014A HOLDER-ZOOM;-,ABS94HB,T0.8,-,-,-
169 AD61-60568A SPRING-ZOOM;-,-,SUS304,-,D0.55,-,SV-S99
170 AD64-10806A KNOB-ZOOM;-,ABS,-,-,-,SV-S99
172 AD90-10828M ASSY-REAR BOARD;VP-L10/BASIC,PAL,NOR,MON
173 AD61-11065A BRACKET-BATT. EJECT;-,STS301,-,T0.5,-,-,
174 AD61-60623A SPRING-BATTERY;-,-,SUS304,PI3.2,8.3,-,VP
175 AD61-30182A LOCKER-BATTERY EJECT;-,POM,-,BLK,-,SV-S9
176 AD61-21014A HOLDER-BATTERY EJECT;-,ABS94HB,-,BLK,-,S
177 AD64-10802A KNOB-BATTERY;-,ABS,-,-,-,SV-S99
179 AD64-30904B CASE-BATTERY;-,ABS94,HB,-,-,BLK,-,VP-L10
180 AD64-60831A INLAY-BATTERY;-,PVC,T0.3,-,BLK,-,SV-S99
181 AD98-12025C ASSY-CASE REAR;VP-L100,-
182 AD61-21132A CAP-A/V JACK;-,ABS 94,HB,BLK,-,VP-L100
184 AD98-11254D ASSY-COVER HOUSING;VP-L100,-
185 AC61-20251A HOLDER-GRIP;PBT,-,BLK,-,VP-K70,-
186 AD61-40379A STOPPER-START/STOP;-,ABS,-,-,-,SV-S99
187 AD59-10328A UNIT-CAP HOOD;VP-K80,-
190 AC61-60068A SPRING-BUTTON;CS,STS304 WPB,P0.2,D4,L7,-
189 AD64-10804A KNOB-START/STOP;-,ABS,-,-,-,SV-S99
188 AD61-60533A SPRING-REC STOP;-,-,STS,T0.2,-,-,VP-A57
191 AD64-10805A BUTTON-START/STOP;-,ABS94HB,-,RED,-,SV-S
193 AC63-10007A GRIP-BELT ASSY;LEATHER,BLK,T1.5,-,SV-H66
194 AD98-11254F ASSY-RIGHT;VP-L100,-
199 AD64-30875H CASE-RIGHT;-,ABS94,HB,D/GRAY,-,VP-L100,-
229 AC61-32047A PLATE-NUT;SECC,T0.8,-,-,SV-V40
900 AC60-10028A SCREW-MACHINE;BH,+,M1.7,X3,ZPC,FE,-,-,-
903 AC60-10020A SCREW-MACHINE;BH,+,M2,X5,FZB,FE,UP,-,-
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB
907 AC60-10024A SCREW-MACHINE;BH,+,M2,X3,FZW,FE,-,-,-
909 AC60-10029A SCREW-MACHINE;BH,+,M1.7,X5.5,ZPC2,FE,-,-
910 AD60-10510A SCREW-MACHINE;-,PLAN,+,-,M1.4X5,5,BLK,FE
911 AD60-10509A SCREW-TAP TITE;-,PWH,+,-,M2X5,5,-
914 AC64-10176A KNOB-RUBBER-LENS;NR,-,BLK,-,VP-K70,-
