Exploded View and Parts List
Samsung Electronics 6-13
Loc. No New Part No Description and Specification Remark
196 AD61-40382A SUPPORT-EVF;-,ABS94,HB,-,BLK,-,SV-S99
197 AD90-10818H ASSY-CRT;VP-L90,-
198 AD90-10810Q ASSY-EVF BOARD;VP-L90,PAL VPL150/VPL100
198 AD90-10810R ASSY-EVF BOARD;SCL90,NTSC SCL150/SCL100
202 AD73-10027A RUBBER-EYE CUP;SILICONE,-,SV-S99,-
203 AD61-21022A HOLDER-EYE CUP;-,-,-,BLK,-,SV-S99
204 AC61-60094A SPRING-PLATE R/EVF;PS,STS301 3/4H,T0.4,D
205 AD60-40650A RING-EVF;-,ID32.8,OD36,T1.6,-,ABS94HB
206 AD67-10196A LENS EVF;PMMA CLR
207 AC61-20179A HOLDER-LENS;ABS 94,HB,BLK,-,VP-K70,-
208 AD61-50688A GUIDE-LENS;-,ABS,-,T1.5,BLK,-,SV-S99
209 AD73-10030A RUBBER-RING EVF;SILICONE,-,SV-S99,-
210 AD98-11223F ASSY-RING EVF;SV-S99,-
211 AD61-70084A RAIL-CASE EVF A;-,POM,-,-,BLK,-,SV-S99
212 AD61-50711A GUIDE-CASE EVF B;-,ABS,-,T1.5,BLK,-,SCL9
213 AD60-40654A PIN-CASE EVF A;-,-,PI1.5,-,SV-S99,STS304
214 AD61-21052B HOLDER-CASE EVF B;-,ABS94HB,-,BLK,-,CS97
216 AD98-12026D ASS’Y CASE-EVF RIGHT VPL150/VPL100
216 AD98-12026E ASS’Y CASE-EVF RIGHT SCL150/SCL100
217 AD61-30192A LOCKER-CASE-EVF A;-,POM,-,BLK,-,SV-S99
220 AD66-80147A LINK-CASE EVF B;-,ABS 94,HB,-,SCL90
223 AD64-30899D CASE-EVF LEFT;-,ABS94V0,-,BLACK,-,VP-L10
229 AC61-32047A PLATE-NUT;SECC,T0.8,-,-,SV-V40
901 AC60-10018A SCREW-MACHINE;BH,+,M2,X3,FZB,FE,UP,-,-
902 AC60-10019A SCREW-MACHINE;BH,+,M2,X4,FZB,FE,UP,-,-
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB
906 AC60-10073A SCREW-TAPTITE;BH,+,-,M2,X6,ZP4,FE
