Samsung SCL100 - Page 91

112 AD90-10828D ASSY-FUNCITION BOARD;VP-L10 S8C-PAL,3INC VP-L150/VP-L100
CN806 3711-000862 CONNECTOR-HEADER;BOX,3P,1R,1.25mm,SMD-A,
R825 2007-000454 R-CHIP;18Kohm,1%,1/10W,DA,TP,2012
R826 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R827 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R828 2007-001124 R-CHIP;68Kohm,1%,1/10W,DA,TP,2012
SW822 3406-000173 SWITCH-ROTARY;16VDC,100MA,10P10T,5.4MM
SW823 63519-105-102 SW-TACT.CHIP;SKHMPT017A
SW824 63519-105-102 SW-TACT.CHIP;SKHMPT017A
122 AD90-10828E ASSY-FUNC MEN BOARD;VP-L10 S8C-PAL,3INCH VP-L150/VP-L100
CN801 3711-000556 CONNECTOR-HEADER;BOX,12P,1R,1.25mm,SMD-A
CN802 3711-002612 CONNECTOR-HEADER;3WALL,5P,1R,1.25MM,SMD-
CN803 3711-000862 CONNECTOR-HEADER;BOX,3P,1R,1.25mm,SMD-A,
CN804 3711-000541 CONNECTOR-HEADER;BOX,2P,1R,1.25mm,SMD-A,
J801 3722-000466 JACK-PHONE;1P/1C,PI3.5,AG,BLK,-
R814 2007-000454 R-CHIP;18Kohm,1%,1/10W,DA,TP,2012
R815 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R816 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R817 2007-001124 R-CHIP;68Kohm,1%,1/10W,DA,TP,2012
R818 2007-000277 R-CHIP;100Kohm,1%,1/10W,DA,TP,2012
R831 2007-000468 R-CHIP;1Kohm,5%,1/10W,DA,TP,2012
R832 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
R881 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R882 2007-000033 R-CHIP;0ohm,5%,1/8W,DA,TP,3216
R883 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R884 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
SW811 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW812 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW813 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW814 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW815 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW825 3403-000126 SWITCH-PUSH;12V,100MA,-,-
110 AD90-10828F ASSY-FUNC VCR BOARD;VP-L10 S8C-PAL,3INCH
CN805 3711-000541 CONNECTOR-HEADER;BOX,2P,1R,1.25mm,SMD-A,
R820 2007-000454 R-CHIP;18Kohm,1%,1/10W,DA,TP,2012
R821 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R822 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R823 2007-001124 R-CHIP;68Kohm,1%,1/10W,DA,TP,2012
R824 2007-000277 R-CHIP;100Kohm,1%,1/10W,DA,TP,2012
R833 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
SW816 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
SW817 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
SW818 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
SW819 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
SW820 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
SW821 3404-001031 SWITCH-TACT;15V,20MA,100GF,4.9X4.9X1.5MM
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
7-12
Samsung Electronics
Electrical Parts List
