Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RP32 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP33 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP34 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP35 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP36 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP37 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP38 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP39 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RP40 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP41 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP42 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP43 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP44 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP45 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP47 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP48 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP49 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RP50 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP51 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP52 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP53 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP54 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP55 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP56 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP57 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP58 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP59 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP60 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RP61 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP62 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP63 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP64 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP65 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
RP66 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP67 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP68 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP70 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP71 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP72 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RP73 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP74 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP75 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP76 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP77 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RP78 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP79 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP80 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP81 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP82 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP83 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
RP84 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP85 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP86 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP87 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP88 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP89 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP90 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RP91 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP92 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP93 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP94 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP95 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP96 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP97 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP98 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RP99 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RW01 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
SW601 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW603 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW604 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW605 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW606 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
T901 AD26-00017A TRANS;-,42uH,8P,15V,460KHz,FERRITE,M
X601 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13 NTSC
X601 2801-003239 CRYSTAL-SMD;11.71875MHz,50ppm,28-ABL,13p PAL
XP01 2801-003919 CRYSTAL-SMD;28.636MHz,40ppm,28-ABL,7pF,6 NTSC
XP01 2801-003918 CRYSTAL-SMD;28.375MHz,40ppm,28-ABL,7pF,6 PAL
XP02 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12
XP03 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13
ASSY-FUNCTION BOARD
CN471 3708-001472 CONNECTOR-FPC/FC/PIC;36P,0.5mm,SMD-A,SN CONNECTOR
CN471 3809-001166 CABLE-FLAT;30V,-20to+80C,110mm,36P,0.5mm FFC
CN473 3708-001334 CONNECTOR-FPC/FC/PIC;10P,0.8mm,SMD-A,SN
CN474 3711-004153 CONNECTOR-HEADER;BOX,14P,1R,1mm,SMD-A,SN
CN475 3711-000779 CONNECTOR-HEADER;BOX,2P,1R,1.25MM,ANGLE,
CN476 3711-000779 CONNECTOR-HEADER;BOX,2P,1R,1.25MM,ANGLE,
LE470 0601-001422 LED;SMD,RED,-,660nm
Q471 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q472 0501-000546 TR-SMALL SIGNAL;KTA1298,PNP,200mW,SOT-23
Q474 0504-001036 TR-DIGITAL;KRA304,PNP,100mW,47K/47Kohm,S
