Samsung Electronics 6-25
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
Q475 0501-000546 TR-SMALL SIGNAL;KTA1298,PNP,200mW,SOT-23
Q476 0504-001036 TR-DIGITAL;KRA304,PNP,100mW,47K/47Kohm,S
Q477 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q479 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q480 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q481 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
R471 2007-000928 R-CHIP;470OHM,1%,1/10W,DA,TP,2012
R472 2007-000454 R-CHIP;18KOHM,1%,1/10W,DA,TP,2012
R473 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R474 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R475 2007-001124 R-CHIP;68KOHM,1%,1/10W,DA,TP,2012
R476 2007-000928 R-CHIP;470OHM,1%,1/10W,DA,TP,2012
R477 2007-000454 R-CHIP;18KOHM,1%,1/10W,DA,TP,2012
R478 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R479 2007-000771 R-CHIP;33KOHM,1%,1/10W,DA,TP,2012
R480 2007-001124 R-CHIP;68KOHM,1%,1/10W,DA,TP,2012
R481 2007-000277 R-CHIP;100KOHM,1%,1/10W,DA,TP,2012
R486 2007-000947 R-CHIP;47OHM,5%,1/10W,DA,TP,2012
R487 2007-000565 R-CHIP;220KOHM,5%,1/10W,DA,TP,2012
R488 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
R489 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
R490 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
R491 2007-000241 R-CHIP;1.5KOHM,5%,1/10W,DA,TP,2012
R492 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R493 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R494 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R495 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R498 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R499 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
SW471 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW472 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW473 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW474 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW475 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW476 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW477 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW478 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW479 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW480 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW481 3404-001037 SWITCH-TACT;12V,50mA,130gf,6x6x4.3mm,SPS
SW482 3409-001108 SWITCH-DETECTOR;5VDC,10mA,1,36gf,LEVER
SW483 3409-001107 SWITCH-DETECTOR;5VDC,1mA,1Poles,26gf,LEV
VR471 2101-001078 VR-ROTARY;1ohm,-,-,TOP
VR472 2101-001077 VR-ROTARY;1ohm,-,-,SIDE
ASSY-EVF BOARD
CNV01 3708-001026 CONNECTOR-FPC/FC/PIC;10P,0.5mm,ANGLE,SN
CNV02 3708-000514 CONNECTOR-FPC/FFC/PIC;16P,0.5mm,SMD-S,SN
CNV03 3708-001436 CONNECTOR-FPC/FC/PIC;4P,1mm,SMD-S,SN
CV05 2203-001734 C-CERAMIC,CHIP;680nF,5%,50V,X7R,TP,2012,
CV09 2203-001734 C-CERAMIC,CHIP;680nF,5%,50V,X7R,TP,2012,
CV10 2203-001734 C-CERAMIC,CHIP;680nF,5%,50V,X7R,TP,2012,
CV11 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV12 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CV13 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV14 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV19 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV20 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV21 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV22 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV26 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV27 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CV28 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
CV29 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608
CV30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV31 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CV33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV37 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CV38 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV39 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV42 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV43 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CV50 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CV51 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV73 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CV74 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
DV01 0405-000123 DIODE-VARACTOR;1T369,34V,10nA,DSM,TP
ICV01 1003-001283 IC-LCD DRIVER;CXA3503R,LQFP,72P,-,SINGLE
ICV02 1103-001133 IC-EEPROM;24C020,256x8BIT,SOP,8P,150MIL,
LV03 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
LV04 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LV06 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LV11 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LV12 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
RV11 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RV12 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
RV13 2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608
RV14 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608
RV16 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
RV17 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV18 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
