Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RV19 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
RV20 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RV21 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RV27 2007-001670 R-CHIP;68OHM,1%,1/10W,DA,TP,2012
RV30 2007-000060 R-CHIP;100Kohm,1%,1/16W,DA,TP,1608
RV32 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV33 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV34 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV40 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RV41 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RV51 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
ASSY-LCD BOARD
CL101 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL102 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL103 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL104 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL105 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL106 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL107 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL108 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL109 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL110 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL137 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL138 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL148 2301-001108 C-FILM,CHIP;22nF,5%,50V,TP,3.2x2.5x1.4,3
CL150 2203-005046 C-CERAMIC,CHIP;0.022nF,5%,3kV,NP0,TP,452
CL157 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL158 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL160 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL161 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL162 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL201 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL202 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL203 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CL204 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL207 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CL208 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL209 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
CL210 2404-000335 C-TA,CHIP;3.3uF,20%,16V,GP,TP,3216
CL211 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL212 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608
CL213 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL214 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL216 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL217 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL218 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL219 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL221 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CL224 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL225 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL226 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL227 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL228 2203-005105 C-CERAMIC,CHIP;0.68nF,5%,50V,NP0,TP,1608
CL229 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL230 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL231 2203-001071 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,160 PAL
CL232 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 PAL
CL233 2203-000062 C-CERAMIC,CHIP;47nF,+80-20%,50V,Y5V,TP,1
CL234 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 PAL
CL235 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 PAL
CL236 2203-001697 C-CERAMIC,CHIP;0.082nF,5%,50V,NP0,TP,160 PAL
CL237 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL238 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 NTSC
CL239 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CL240 2404-000251 C-TA,CHIP;470nF,20%,35V,-,TP,3216,-
CL302 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL303 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL304 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CL309 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL310 2203-001052 C-CERAMIC,CHIP;0.56nF,10%,50V,X7R,TP,160
CL311 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL312 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CL313 2203-001598 C-CERAMIC,CHIP;2200nF,+80-20%,16V,Y5V,TP
CL314 2203-001697 C-CERAMIC,CHIP;0.082nF,5%,50V,NP0,TP,160
CL315 2404-000232 C-TA,CHIP;4.7uF,20%,10V,-,TP,3216,-
CL316 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL317 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL318 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL319 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL320 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL324 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL325 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL326 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL327 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL328 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL329 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
CL331 2404-000130 C-TA,CHIP;10uF,20%,20V,-,TP,6032,-
CL340 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CNL101 3711-004153 CONNECTOR-HEADER;BOX,14P,1R,1mm,SMD-A,SN
