Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CNL102 3708-001334 CONNECTOR-FPC/FC/PIC;10P,0.8mm,SMD-A,SN
CNL301 3708-001340 CONNECTOR-FPC/FC/PIC;24P,0.5mm,SMD-A,SN
DL302 0405-000123 DIODE-VARACTOR;1T369,34V,10nA,DSM,TP
DL303 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
ICL201 1002-001125 IC-D/A CONVERTER;M62366GP,8BIT,SSOP,20P,
ICL202 1103-001133 IC-EEPROM;24C020,256x8BIT,SOP,8P,150MIL,
ICL203 1204-001321 IC-VIDEO PROCESS;IR3Y29BM,QFP,48P,286MIL
ICL301 1201-000200 IC-OP AMP;3414,SOP,8P,173MIL,DUAL,-,PLAS
ICL303 1003-001261 IC-LCD CONTROLLER;CM7019L3-T4,QFP,48P,27
LL101 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LL102 2703-000407 INDUCTOR-SMD;330uH,10%,3.2x2.5x2.2mm
LL103 2703-000407 INDUCTOR-SMD;330uH,10%,3.2x2.5x2.2mm
LL104 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL105 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LL106 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LL109 2703-001196 INDUCTOR-SMD;150uH,20%,7x7x3.2mm
LL115 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
LL201 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL202 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
LL205 AD27-00002A COIL-TRAP;5CDM,-,Q1C,M7N,-,SUMIKASUPER-E PAL
LL301 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LL302 2703-000367 INDUCTOR-SMD;33uH,5%,2.5x2x1.8mm
LL304 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LL306 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
QL101 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QL103 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
QL108 0502-001182 TR-POWER;KTD1898,NPN,500mW,SOT-89,TP,12
QL109 0502-001182 TR-POWER;KTD1898,NPN,500mW,SOT-89,TP,12
QL110 0501-002311 TR-SMALL SIGNAL;HN2A01FU,PNP,200mW,UMD6,
RL106 2007-000979 R-CHIP;5.6Kohm,1%,1/16W,DA,TP,1608
RL107 2007-000063 R-CHIP;150Kohm,1%,1/16W,DA,TP,1608
RL136 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL137 2007-000516 R-CHIP;2.7Kohm,1%,1/16W,DA,TP,1608
RL140 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RL141 2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608
RL142 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL201 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL202 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL203 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL204 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL205 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL207 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL208 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL209 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
RL210 2007-000133 R-CHIP;330Kohm,5%,1/16W,DA,TP,1608
RL212 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RL215 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RL216 2007-000133 R-CHIP;330Kohm,5%,1/16W,DA,TP,1608
RL217 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
RL218 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
RL221 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
RL222 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608
RL223 2007-000939 R-CHIP;47Kohm,1%,1/16W,DA,TP,1608
RL224 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL225 2007-000939 R-CHIP;47Kohm,1%,1/16W,DA,TP,1608
RL226 2007-001038 R-CHIP;56Kohm,1%,1/16W,DA,TP,1608
RL233 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RL234 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
RL235 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RL236 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL237 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL238 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RL239 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RL240 2007-000305 R-CHIP;10Mohm,5%,1/16W,DA,TP,1608
RL241 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608 PAL
RL242 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
RL243 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 NTSC
RL243 2007-007703 R-CHIP;5.6MOHM,5%,1/16W,DA,TP,1608
RL244 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 PAL
RL245 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RL246 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
RL247 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL248 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL250 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL251 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL261 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL262 2007-001007 R-CHIP;51Kohm,1%,1/16W,DA,TP,1608
RL263 2007-000651 R-CHIP;27Kohm,1%,1/16W,DA,TP,1608
RL265 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RL266 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 NTSC
RL270 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL271 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL276 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL278 2007-000805 R-CHIP;36Kohm,5%,1/16W,DA,TP,1608
RL279 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RL301 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608
RL302 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RL303 2007-000736 R-CHIP;30Kohm,1%,1/16W,DA,TP,1608
RL304 2007-000060 R-CHIP;100Kohm,1%,1/16W,DA,TP,1608
RL305 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
