Samsung Electronics6-28
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RL306 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RL307 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RL308 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RL309 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RL310 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RL311 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RL312 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RL313 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RL314 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL315 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RL316 2007-000616 R-CHIP;24Kohm,5%,1/16W,DA,TP,1608
RL317 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
RL318 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608
RL320 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
RL321 2007-000805 R-CHIP;36Kohm,5%,1/16W,DA,TP,1608
RL322 2007-000491 R-CHIP;2.2Kohm,1%,1/16W,DA,TP,1608
RL323 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 PAL
RL324 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 NTSC
RL331 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
SWL101 3409-001081 SWITCH-DETECTOR;12V DC,0.1A,SPST,30gf,PU
TL103 AD26-82001C TRANS-INVERTER;12.4X11X3.4,6V,101KHZ,843
XL201 2801-003866 CRYSTAL-SMD;4.43362MHz,30ppm,28-ABY,16pF
ASSY-CCD BOARD
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
CC02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNC01 3711-004241 CONNECTOR-HEADER;BOX,18P,2R,1MM,SMD-A,SN
DC02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
QC01 0505-000180 FET-SILICON;2SK1070PIETR,-,150MW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC07 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ASSY-FRONT BOARD
CN801 AD39-00035A LEAD CONNECTOR-ASSY;2.0/1.25,12P,70MM,3502
CN802 3711-000780 CONNECTOR-HEADER;BOX,2P,1R,1.25mm,STRAIG
J801 3722-001441 JACK-PHONE;3P,3.6PI,AG,BLK,-
J802 3722-001440 JACK-PHONE;4P,3.6PI,SN,YEL,-
RE801 AD32-00007A MODULE REMOCON;-,KSM-603TM,37.9KHz,940nm
ASSY-REAR BOARD
BT451 AD63-00072A TERMINAL--BATTERY;T0.3,C5210R-H,-,-,-
BT452 AD63-00072A TERMINAL--BATTERY;T0.3,C5210R-H,-,-,-
C451 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CN451 3710-001106 CONNECTOR-SOCKET;40P,2R,0.8mm,SMD-S,SN
CN452 3710-001479 CONNECTOR-SOCKET;14P,2R,1MM,SMD-S,SN
D451 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D452 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
IC451 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
J451 AD97-01199A ASSY-DC JACK;M1-PJ,-,-
J452 AD97-01200A ASSY-S-JACK;M1-PJ,-,-
PS451 3601-001154 FUSE-SURFACE MOUNT;125V,2.5A,SLOW-BLOW,C
Q451 0505-001417 FET-SILICON;TPC8303,P,-30V,-4.5A,55mohm,
Q452 0501-000546 TR-SMALL SIGNAL;KTA1298,PNP,200mW,SOT-23
Q453 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q454 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q455 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q456 0504-001047 TR-DIGITAL;DTA124EUA,PNP,200MW,22K/22K,S
R451 2007-000922 R-CHIP;470KOHM,1%,1/10W,DA,TP,2012
R452 2007-000562 R-CHIP;220KOHM,1%,1/10W,DA,TP,2012
R453 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
R454 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R455 2007-002749 R-CHIP;3.3OHM,5%,1/8W,DA,TP,3216
R456 2007-000978 R-CHIP;5.6KOHM,1%,1/10W,DA,TP,2012
R457 2007-000465 R-CHIP;1KOHM,1%,1/10W,DA,TP,2012
R458 2007-000406 R-CHIP;15KOHM,1%,1/10W,DA,TP,2012
R459 2007-000465 R-CHIP;1KOHM,1%,1/10W,DA,TP,2012
R466 2007-007948 R-CHIP;0.1ohm,1%,0.75W,DA,TP,5025
R472 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012
R473 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012
SW471 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,R
SW473 3404-001117 SWITCH-TACT;12V,50mA,130gf,8.0x3.7x2.5mm
SW474 3404-001119 SWITCH-TACT;12V,50mA,130gf,6.2x6.2x2.6mm
SW475 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,R
VR471 2102-001019 VR-SLIDE;10Kohm,30%,1/20W,SLIDE
