Samsung SCX-4216F Series - Page 28

3-14 Samsung Electronics
Disassembly and Reassembly
3-12 Front Cover
1. Take out the Cassette.
2. OPen the Front Cover.
3. Unlatch the Front Cover securing the Frame Ass'y.
Then remove the Front Cover, as shown below.
Cassette
Front Cover
