English _1
English
SAMSUNG ALL-IN-ONE SECURITY SYSTEM
KIT MODEL
SDS-P3042 / V3042/ S3042/ P3022/ P4042 / V4042/
S4042/ P4082/ P5082 / S5082 / P5102 / P5122
DVR MODEL
SDR-3102
/
4102
/
5102
Quick Start Guide
Thank you for purchasing a Samsung DVR Security System.
Follow the simple steps in this guide to set up and start using your new system.
If you have any questions or need help installing your new product please contact our free technical support.
Telephone: 1-877-349-3149
9am - 9pm EST, Monday - Friday
Internet: http://www.samsungsv.com
INSTALLING YOUR SYSTEM
M
Images may differ depending on the model.
❒
4CH DVR
Front
Rear
1
Connect a mouse
4
Connect the DC adaptors
2
Connect a camera
5
Connect to a network router
3
Connect a monitor
POWER REC NETWORK
1
IN1
IN3
IN4
AUDIO IN
AUDIO OUT
VGA
IN2
HDMI
eSATA
VIDEO IN
LAN
USB
RS485
DC12V
2
3
4
5

Table of Contents

Questions and Answers

  • Z
    Zachary CollinsSep 14, 2025
    Why do some channels display a black screen on my Samsung SDR-4102?
    • L
      lewisamySep 15, 2025
      If some channels display just a black screen on your Samsung Security System, check if the camera connected to the system properly displays the image and if the camera is properly supplied with power. This problem may also occur on a channel with a weak video signal from a video distributor connected to multiple systems; in this case, input the video source of the camera directly into the DVR.
  • H
    Hannah HayesAug 25, 2025
    Why is my Samsung DVR not recording?
    • M
      Michael WilsonAug 25, 2025
      If your player does not display a Live image at all, that indicates recording does not work, so first check if you see an image on the screen. Recording does not work if the recording settings are not properly configured. To start recording manually, press the [REC] button on the remote control. To schedule recording, specify a desired time in Menu – Record – Recording Schedule. Continuous Recording will proceed in any conditions at the specified time. Event Recording will perform only if the event is of alarm, motion detection, video loss and Tampering Detection. If there is no event found, Continuous recording will perform. Whereas, if an event occurs, Event recording will perform.
  • A
    Amy JohnsonAug 25, 2025
    How to improve the recording quality on my Samsung DVR?
    • C
      Crystal OliverAug 26, 2025
      To enhance the image quality of your recorded data, increase the resolution and quality level in Menu – Record – Quality / Resolution. You can select a bigger size when specifying the recording size and specify a bigger level for the recording quality.
  • L
    lisa30Aug 26, 2025
    Why can't I play backup data from my Samsung DVR on my PC?
    • K
      kaufmanlindsayAug 26, 2025
      When you are backing up data, you have choices about the player either: PC or DVR. Make your selection before proceeding. If you are using the PC to play the data, the format of the backup file should be SEC. If you are using the DVR for this purpose, formatting backup files should be done by the DVR.
  • K
    Kelsey AriasSep 15, 2025
    What to do if the REC button doesn't work on my Samsung Security System?
    • S
      srivasSep 15, 2025
      If the REC indicator does not flash and the player does not start recording when you press the [REC] button on your Samsung Security System, check if there is free space on the HDD for recording and if the record mode is set to ON in the record mode setting.
  • H
    Hailey DixonSep 23, 2025
    What to do if the ESC key doesn't exit full screen mode in WebViewer on my Samsung SDR-4102 Security System?
    • H
      hamptonmarissaSep 23, 2025
      If pressing the ESC key in full screen mode of the WebViewer on your Samsung Security System does not switch the system to a normal split mode, press the ALT+TAB keys to select ‘ACTIVE MOVIE’ and press the ESC key again.
  • M
    Mark HoltSep 7, 2025
    Why is the Channel button not working on my Samsung DVR Live screen?
    • S
      Stephanie PhillipsSep 7, 2025
      The Channel button does not work if the current screen is in the event monitoring mode. Press the [ALARM] button to exit the screen and select a channel.
  • E
    Erin RogersSep 8, 2025
    Why can't I move the cursor to the Start button in calendar search on my Samsung DVR?
    • M
      michaelbrennanSep 8, 2025
      Check if the channel and the date that you want to play are marked with the V symbol.
  • K
    Kimberly WoodSep 2, 2025
    Why doesn't my Samsung DVR recognize all of my external HDDs?
    • K
      Kyle WilliamsonSep 2, 2025
      It takes time for the DVR to recognize multiple external HDDs, so try again in a moment. The problem may occur due to a mechanical error of the HDD installed, so try again with a different HDD.
  • H
    huntheatherAug 31, 2025
    What does NO HDD icon mean on my Samsung DVR?
    • J
      Joseph GarrettAug 31, 2025
      Check the HDD for connection. If the problem persists in a normal condition, contact the nearest service center to have the HDD checked by the service personnel.
