SPEED DOME CAMERA User’s Manual
76
SPEED DOME CAMERA User’s Manual
77
Camera Status
CAM MODEL = 37PC
CAM VERSION = 2.3
DOME VERSION = 0.10
CON PROTOCOL = SAMSUNG TW
DOME ID = 001
CONTROLLER = Simplex-9600
TRACK VERSION = 0.10
Main Menu
①Camera Setting
②Sequence Setting
③P/T Setting
④OSD Setting
⑤Alarm Setting
⑥Initialize
Status
➡
27. Status
 ▶
Main Menu/Status
Displays the settings and version of the dome camera.
Cam Model
:
Indicates the model name of the camera.
Cam Version
:
Indicates the software version of the camera.
Dome Version
:
Indicates the version of the camera control board.
CON Protocol
:
Indicates the status of the current protocol.
Dome ID
:
Dome Camera ID
Controller
:
Indicates the settings of the current communications mode.
Track Version
:
Indicates the Auto Track software version of the camera.
Operating Your Camera
Status
SPD-3750T SPD-3750 SPD-3350
Imaging Device
1/4 inch, Double Density Interline Transfer CCD
TV Standard
NTSC / PAL
Total Pixels
NTSC:811(H) x 508(V) / PAL:795(H) x 596(V)
Effective Pixels
NTSC:768(H) x 494(V) / PAL:752(H) x 582(V)
Scanning System
2:1 Interlace
Synchronization
Internal Internal/External(AC Line Lock)
Horizontal Scan Rate
NTSC:15.734 KHz / PAL:15.625 KHz
Vertical Scan Rate
NTSC:59.94 Hz / PAL: 50 Hz
Horizontal Resolution
550 TV Line(Color)/680 TV Line(B/W)
Min. Illumination
0.7 Lux @ F1.6 ( Color ), 0.002Lux @ F1.6 (Sens-up 256X)
0.03 Lux @ F1.6 ( B/W )
S/N (Y Signal)
50 dB
Video Output
CVBS:1.0Vp-p/75Ω
Zoom Ratio
37X (Optical),12X (Digital) 33X (Optical),12X (Digital)
Focal Length
3.5~129.5mm (F1.6 ~3.9) 3.5~115.5mm (F1.6 ~3.6)
Min. Object Distance
1.9m
Angular Field
of view
H:55.5°(Wide)~1.59°(Tele) H:55.5°(Wide)~1.77°(Tele)
V:42.5°(Wide)~1.19°(Tele) V:42.5°(Wide)~1.33°(Tele)
Focus
AUTO / MANUAL / ONE-SHOT
Zoom Speed
2.5sec
IRIS
AUTO/MANUAL
Lens Initialization
Built-In
Auto Tracking
Built-In -
Horizontal
Rotation Angle
360° Endless
Horizontal
Rotation Speed
Manual:0.024°/sec ~120°/sec, Preset 500°/sec
Vertical Rotation Angle
-5° ~ 185°
Vertical Rotation Speed
Manual:0.024°/sec ~120°/sec, Preset 500°/sec
Preset Position
255
Preset Accuracy
±0.1°
Camera ID
255
Day & Night
AUTO / COLOR / BW
Backlight
WDR / USER / HLC / OFF
Dynamic Range
52dB
Motion Detection
ON/OFF
Stabilizer
ON/OFF
Privacy Mask
ON/OFF (8 Areas)
SSNR
LOW/MEDIUM/HIGH/OFF
Sens-up
On/Off (Selectable limit ~ 256X )
Gain Control
LOW/MEDIUM/HIGH/MANUAL/OFF
White Balance
ATW/INDOOR/OUTDOOR/AWC/MANUAL
Product Specification
