10. Disassembly & Assembly
10-1. Replacement of refrigerator lamp
1. Remove the cover with the back latch pressed.
2. Pull out the lamp.
3. After replacing the lamp, assemble the front latch of
cover and then connect the back latch.
4. Plug in and check if power is cut off or not by pressing
the R-door switch.
Warning
Always take out the power plug when replacing the refrigerator lamp. There is the
danger of electric shock.
53
1. Remove a screw from the cover and pull down the
cover with the back latch pressed.
2. Pull out the lamp.
3. After replacing the lamp, assemble the front latch of
cover and then connect the back latch and screw on the
cover.
Warning
Always take out the power plug when replacing the refrigerator lamp. There is the
danger of electric shock.
10-2. Replacement of refrigerator fluorescent lamp
