Samsung SRF653CDLS - Door Removal Procedure

English - 18
Required Tools (Not provided)
Youneedthefollowingtoolstocompletethe
installationofyourrefrigerator:
Philips
screwdriver(+)
Flat-bladescrew
driver(-)
Socketwrench
(13/32”)(10mm)
Pliers
Allenwrench
(3/16”)(5mm)
With the door opened
1. Remove3screwsholdingdowntheTOP
TABLE(1)andseparatetheconnectedwires.
(1)
2. Disconnecttwoconnectors(2)ontheleftside
door.
Toremovethewatercouplerfromthehinge,
twistandpullitfromthehinge.
Removethewaterline(3)whilepressingthe
markedpart(4)ofthewaterlinecoupler.
(2)
(3)
(4)
3. Pullandremovethehingelever(5).
Removethegroundscrew(6)attachedtothe
upperleftdoorhingeswithaphilipsscrewdriver
(+).Removetheupperleftandrightdoor
hinges(7).
(5)
(7)
(6)
4. Liftthedoorstraightuptoremove.
5. Removethescrew(8)attachedtothe
lowerleftandrightdoorhingeswithaphilips
screwdriver(+).
Removethe2hexheadbolts(9)attachedto
thelowerleftandrightdoorhingeswithanallen
wrench(3/16”).
Removethelowerleftandrightdoorhinges
(10).
Allen wrench
(10)
(8)
(9)
