Samsung SRF653CDLS - Installing the Water Dispenser Line

English - 21
SETTING UP
MAKING MINOR ADJUSTMENTS
BETWEEN DOORS
Remember,aleveledrefrigeratorisnecessaryfor
gettingthedoorsperfectlyeven.
Ifyouneedhelp,reviewtheprevioussectionon
levelingtherefrigerator.
Adjustment part
Fixed part
Theleftdoorisxed.
Tomakeminoradjustmentsbetween
doors,adjustonlytherightdoor.
1. Pulloutthefreezerdrawer(1)torevealthe
lowerhinge(2).
2. Insertaphilipsscrewdriver(+)(3)intotheshaft
(4)ofthelowerhinge.
3. Adjusttheheightbyturningaphilips
screwdriver(+)(3)clockwise(
DOWN
)or
counterclockwise(
UP
).
(3)
(1)
(3)
(2)
(4)
Whenyouturnaphilipsscrewdriver(+)
counterclockwise( ),thedoorwill
moveup.
INSTALLING THE WATER
DISPENSER LINE
Awaterdispenserwithalterisoneofthehelpful
featuresonyournewrefrigerator.
Tohelppromotebetterhealth,thewaterlter
removesunwantedparticlesfromyourwater.
However,itdoesnotsterilizeordestroy
microorganisms.
Youmayneedtopurchaseawaterpurifying
systemtodothat.
Inorderfortheicemakertooperateproperly,a
waterpressureof138~862kPaisrequired.
Undernormalconditions,a170cc(5.75oz.)cup
canbelledinabout10seconds.
Iftherefrigeratorisinstalledinanareawithlow
waterpressure(below138kPa),youcaninstalla
boosterpumptocompensateforthelowpressure.
Afteryouhaveconnectedthewaterline,make
surethewaterstoragetankinsidetherefrigerator
isproperlylled.
Todothis,pressthewaterdispenserleveruntilthe
waterrunsfromthewateroutlet.
Waterlineinstallationkitsareincludewith
unit.Youcannditinfreezerdrawer.
Thenewhose-setssuppliedwiththe
appliancearetobeusedandthatold
hose-setsshouldnotbereused.
Parts for water line Installation
Waterlinexerandscrews Pipeconnector
Waterline
