Samsung SRF653CDLS - Reattaching the Refrigerator Doors

English - 19
SETTING UP
REATTACHING THE
REFRIGERATOR DOORS
Toreattachthefridgedoorsafteryouhavemoved
thefridgetoitsnallocation,assemblethepartsin
reverseorder.
1. TheWaterLinemustbefullyinsertedintothe
centerofthetransparentcoupler(TypeA)orthe
GuideLines(TypeB)topreventwaterleakage
fromthedispenser.
Center of Transparent
coupler
The Guide Lines
Dispenser
Type A Type B
DISASSEMBLE THE FREEZER
DRAWER
1. Takeouttheupperdrawerbyliftingitup.
2. Removethefreezeroomguard(1)bylifting
theguardup.
(1)
3. Takeoutthelowerbasket(2)byliftingthe
basketupfromtherailsystem.
(2)
Youcanscratchthesideofthebinifyou
twistitleftorrightwhendisassemblingor
re-assemblingit.
4. Pressthexinghookoftherailsystem.
5. HoldingthetopoftheFreezerDrawer,pullit
outalltheway,andthenremoveitfromtherail
system.
Becarefulnottoscratchordentthe
slidingrailbylettingitstriketheoor.
Makesurethatyoumountthefreezer
basketintherightpositionwhenremoving
/installingthefreezerdoor.
Failingtodosomayresultinthedoornot
openingorclosingproperly.
CAUTION
CAUTION
CAUTION
