CN601 305 97 3711-000217 CON-WALL HEADER,3P,3.96 STRAIGHT,1WALL
CN602 272.5 77 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN603 265 77 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN604 311.5 74.8 3722-001100 JACK-DIN 4P/2C,6mm,AG,BLK,NO
CN606 300.3 82 3711-000178 CONNECTOR-HEADER 1WALL,2P,1R,3.96mm,STRAIGHT,SN
CRT1 282.8 188 BH03-10301G CRT,COLOR,14 M34KUK35X01
D101 258.5 153 0402-000007 DIODE-REC,1N4937,DO-41 420V,1A,1.2V,1A,200NS,1A
D101B 274 219.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D101G 269 219.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D101R 266.5 219.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D102B 281.5 230.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D102G 286.5 230.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D102R 291.5 230.5 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D103B 313.5 194 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D103G 312 210.3 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D103R 313.3 230.8 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D205 228.5 130 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D206 231 130 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D207 233.5 130 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D208 237.5 126.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D209 237.5 124 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D210 237.5 121.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D211 214.5 109.5 0403-000005 DIODE-ZEN,UZ-5.1B,DO-35 0.5W,10MA
D213 227.5 107 0403-000005 DIODE-ZEN,UZ-5.1B,DO-35 0.5W,10MA
D214 259.5 117.3 0403-000005 DIODE-ZEN,UZ-5.1B,DO-35 0.5W,10MA
D215 259.5 114.8 0403-000005 DIODE-ZEN,UZ-5.1B,DO-35 0.5W,10MA
D216 66.5 134.3 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D301 130.5 41 0402-000128 DIODE-REC,1N4002,DO-41 70V,1A,1.1V,1A,2000NS,0.5A
D401 80 230 0402-000007 DIODE-REC,1N4937,DO-41 420V,1A,1.2V,1A,200NS,1A
D402 72.5 232.1 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D403 135.5 207.8 0404-000001 DIODE-SCHOTTKY FMP-G2FS,1500V,5A,TO-220,ST
D404 66.5 221.3 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D405 71.3 178.8 0402-000128 DIODE-REC,1N4002,DO-41 70V,1A,1.1V,1A,2000NS,0.5A
D406 26.5 206 0402-000006 DIODE-RECTIFIER 1N4007GP,1000V,1A,DO-41
D407 16 206 0402-000006 DIODE-RECTIFIER 1N4007GP,1000V,1A,DO-41
D408 121 232 0402-001112 DIODE-RECTIFIER MDV04-600,600V,4A,DO201,BK
D409 127.3 234.3 0402-001025 DIODE-RECTIFIER ERD07-15,1500V,1.5A
D410 40.5 139 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D411 61 188.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D412 61 134.3 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D413 58.5 126.3 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D414 138.5 186.5 0402-000007 DIODE-REC,1N4937,DO-41 420V,1A,1.2V,1A,200NS,1A
D418 58.3 206.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D501 116 133.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
D502 187 120.3 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D503 187 122.8 0401-000006 DIODE-SWITCHING BAV21,200V,250mA,400mW,50nS,DO
D507 213 155.5 0401-000005 DIODE-SIG,1N4148,DO-35 75V,150MA,1V,10MA
