CKA42*7L/5227L 2-1
2 Product Specifications
2-1 Specifications
Picture Tube: CKA42*7L: 14-Inch (36 cm); 13.2-Inch (33.5 cm) viewable, 90° Deflection,
CKA5227L: 15-Inch (38 cm); 13.8-Inch (35 cm) viewable, flat-face tube, 90° Deflection,
0.28 mm Dot pitch, Semi-tint, Non-glare, Antistatic silica coating, Invar shadow mask
Scanning Frequency Horizontal : 30 kHz to 55 kHz (Automatic)
Vertical : 50 Hz to 120 Hz (Automatic)
Display Colors Unlimited colors
Maximum Resolution Horizontal : 1024 Dots
Vertical : 768 Lines
Input Video Signal Analog, 0.714 Vp-p positive at 75 Ω, internally terminated
Input Sync Signal Separate Sync : TTL level positive/negative
Maximum Pixel Clock 65 MHz
Active Display CKA42*7L CKA5227L
Horizontal 255 mm ± 3 mm (4:3 ratio) 267 mm ± 3 mm (4:3 ratio)
Vertical 191 mm ± 3 mm 200 mm ± 3 mm
Input Voltage AC 90 to 264 Volts, 60 Hz/50 Hz ± 3 Hz
Power Consumption 73 Watt (max)
Dimensions CKA42*7L CKA5227L
Unit (W x D x H) 13.7 x 15.2 x 14.3 Inches (348 x 385 x 362.5 mm) 14.6 x 15.6 x 14.8 Inches (370 x 395 x 377 mm)
Carton (W x D x H) 16.6 x 18.1 x 15.4 Inches (422 x 460 x 390 mm) 17.9 x 19.6 x 17.0 Inches (454 x 497 x 433 mm)
Weight (Net/Gross) CKA42*7L : 23.1 lbs (10.5 kg) / 27.3 lbs (12.4 kg)
CKA5227L : 27.6 lbs (12.5 kg) / 30.9 lbs (14.0 kg)
Environmental Considerations Operating Temperature : 32°F to 104°F (0°C to 40°C)
Humidity : 10 % to 80 %
Storage Temperature : -4°F to 113°F (-20°C to 45°C)
Humidity : 5 % to 95 %
CRT Code No.
• CKA42*7L/5227L complies with SWEDAC (MPR II) recommendations for reduced electromagnetic fields.
• Designs and specifications are subject to change without prior notice.
